Samtec IPBT Series Straight Through Hole PCB Header, 20 Contacts, 4.19 mm Pitch, 2 Row, Shrouded IPBT-110-H1-T-D-K

The Samtec IPBT-110-H1-T-D-K is a straight through hole PCB header built for robust wire-to-board connectivity in industrial and electronic applications. This component features 20 individually shrouded male contacts arranged in two rows, with each contact spaced 4.19 mm apart, ensuring reliable compatibility with PCBs conforming to standard layouts.

The header is constructed with a liquid crystal polymer housing, delivering high thermal resistance and mechanical strength. The shrouded body structure shields the contact pins, reducing the risk of accidental damage and improving connection reliability in high-density boards and harsh environments.

Operating safely at currents up to 10A and voltages up to 565V, this header is suitable for circuits requiring dependable power distribution and signal transmission. The component performs reliably across a broad temperature range, from -55°C to 105°C, making it ideal for both commercial and industrial electronics.

Through hole mounting provides a secure fit, and the tin-plated copper alloy contacts ensure excellent electrical conductivity and resistance to corrosion. Solder termination allows for straightforward integration into manufacturing processes.

With its dual-row configuration and individually shrouded contacts, the IPBT-110-H1-T-D-K supports versatile PCB layouts and offers optional polarized guide post holes for additional alignment support. The device is designed under the Samtec IPBT Series, known for offering elevated stack height options and strong current handling capabilities.

Typical applications include industrial control systems, embedded electronics, automation assemblies, laboratory instruments, manufacturing PCBs, and other environments needing robust, high-reliability wire-to-board headers. The shrouded design protects both the header and plug during insertion and operation, minimizing maintenance needs and increasing system durability.
