Samtec TMS Series Straight Through Hole Pin Header, 4 Contacts, 1.27 mm Pitch, Unshrouded, Board-to-Board TMS-104-01-L-S
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 5A |
| Model | TMS-104-01-L-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TMS |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
| Contact System | .018" (0.46 mm) square post |
Key Features
- Suitable for board-to-board applications in PCB design.
- Through-hole mounting for secure soldering and electrical reliability.
- Contacts constructed from phosphor bronze, plated with gold for enhanced conductivity and durability.
- 1.27 mm pitch and single row layout offers compact form factor for space-constrained electronics.
- Minimum operating temperature of -55°C and maximum operating temperature of 125°C for broad environmental tolerance.
- Liquid Crystal Polymer housing delivers high mechanical and thermal stability.
- Male contact gender with tail pin length of 3.05 mm, mating pin length of 5.84 mm.
- Optional polarization feature allows for design flexibility.
Product Description
The Samtec TMS-104-01-L-S is a specialized straight through hole pin header designed for advanced PCB applications where reliable board-to-board connections are required. This pin header features four phosphor bronze contacts configured in one row with precise 1.27 mm pitch, making it ideal for compact circuit layouts and high-density PCB assemblies.
Its through-hole mounting ensures mechanical stability and excellent soldering integrity, which is critical for industrial, laboratory, and embedded electronics. The contacts are plated with gold, providing enhanced performance by reducing electrical resistance and maximizing corrosion protection.
The housing is made from liquid crystal polymer, a high-performance engineering material renown for mechanical strength, thermal stability, and compatibility with advanced PCB manufacturing processes. The single row, unshrouded design streamlines integration for applications requiring direct mating and easy insertion.
With a minimum operating temperature of -55°C and maximum of 125°C, the TMS-104-01-L-S pin header can be confidently deployed in wide-ranging industrial environments, including instrumentation, control, automation, and demanding laboratory setups. Its optional polarization capability accommodates both single and double row up to 100 pins for tailored design flexibility.
Technical features include male contact gender, tail pin length of 3.05 mm, mating pin length of 5.84 mm, and a contact system utilizing .018 inch (0.46 mm) square posts. Termination is by soldering, assuring permanent and low-resistance connections.
Applications for the Samtec TMS series pin headers extend to industrial control PCBs, scientific instruments, electronics manufacturing, and commercial equipment requiring precise and robust board-to-board connectivity.
For further exploration of PCB Header solutions, browse the Samtec range and related PCB connector categories on EnvMart for compatible products and advanced electronic components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this pin header is 1.27 mm, allowing for compact layouts in PCB designs.
The maximum operating temperature for the TMS-104-01-L-S is 125°C, making it suitable for various industrial applications.
This model utilizes through-hole mounting, ensuring secure soldering and mechanical stability.
The contacts are made from phosphor bronze and are plated with gold to enhance conductivity and reduce corrosion.
This pin header features four contacts, arranged in a single row.
The tail pin length of the TMS-104-01-L-S is 3.05 mm, while the mating pin length is 5.84 mm.
The minimum operating temperature for this pin header is -55°C, allowing for use in extreme conditions.
This pin header has a male contact gender, designed for board-to-board connections.
The termination type for this model is solder, ensuring permanent connections.
The housing is made from liquid crystal polymer, providing high mechanical and thermal stability.
This pin header is suitable for industrial control PCBs, scientific instruments, and electronics manufacturing requiring reliable board-to-board connectivity.
Yes, the TMS-104-01-L-S offers an optional polarization feature that accommodates both single and double row configurations up to 100 pins.
