Samtec IPL1 Series Straight Surface PCB Header, 4 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, Phosphor Bronze, Male,
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 954V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features 4 individually shrouded contacts for secure connection stability.
- 2.54 mm pitch is standard for easy PCB integration and promotes versatile compatibility.
- Current rating up to 3.8A ensures robust performance in demanding electronic circuits.
- Double row and shrouded design enhances signal integrity and protects contact points.
- Manufactured from liquid crystal polymer housing and tin-plated phosphor bronze contacts for longevity and corrosion resistance.
- Straight surface mount orientation simplifies automated assembly and provides secure fit.
- Male contact gender supports signal transmission for data or power lines on PCBs.
- Wide operating temperature range from -55°C to 125°C for industrial reliability.
Product Description
The Samtec IPL1-102-01-S-D-RA-K is a straight surface mount PCB header engineered for robust wire-to-board connectivity in electronic assemblies. Designed with a 2.54 mm pitch and 4 individually shrouded contacts, this header offers consistent signal transmission and mechanical stability, suitable for both data and power applications.
The double row configuration allows for increased circuit density and flexibility within PCB layouts. Features such as shrouded contacts minimize accidental unplugging and protect internal connections from contaminants. With a current rating of up to 3.8A, the IPL1-102-01-S-D-RA-K meets requirements for demanding circuits in industrial, automation, and commercial electronics.
The housing is constructed from liquid crystal polymer, a material noted for its strength, heat resistance, and insulating properties. Tin-plated phosphor bronze contacts resist corrosion and provide reliable electrical conduction. The male contact gender is well suited for pairing with corresponding female sockets or connectors.
Integration is further simplified by straight surface mount orientation, making this header ideal for automated manufacturing processes. The solder termination supports robust PCB attachment and stable performance under various environmental conditions.
Operating temperatures range from -55°C to 125°C, ensuring endurance in both low- and high-heat industrial environments. The device is rated for up to 954V and meets critical standards for electronic safety and performance.
The Samtec IPL1-102-01-S-D-RA-K PCB header is recommended for use in circuit boards across industrial automation, instrumentation, telecommunications, commercial electronics, and manufacturing equipment. Its high durability and electrical reliability make it an excellent choice for engineers and OEMs seeking consistent, long-term performance in surface-mounted designs.
Explore more Samtec PCB Headers, connectors, and board-to-board solutions in the Electronics & Electricals category on EnvMart.
