Wurth Elektronik WR-TBL Series Pluggable Terminal Block, 4-Contact, 3.81 mm Pitch, 1 Row, 8A Current, 1.6kV AC 691348300004
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.6kV ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 8A |
| Length | 16.12mm |
| Depth | 18.3mm |
| Width | 11.1mm |
| Housing Material | Polyamide 66 |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 4 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 2.08mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Designed for a current rating of 8 amperes.
- Supports a working voltage up to 1.6kV AC.
- Constructed with durable Polyamide 66 housing material.
- Utilizes brass contact materials for optimal conductivity.
- Vertical orientation with screw wire connection method.
- Compatible with wire sizes ranging from 30 AWG to 14 AWG (0.05 mm² to 2.08 mm²).
- Operating temperature range from -40°C to +115°C.
- Features tin-plated contacts and zinc-plated steel terminal screws.
Product Description
Wurth Elektronik 691348300004 is a high-quality WR-TBL Series pluggable terminal block designed for secure and efficient PCB connections. This model offers a 4-contact configuration with a 3.81 mm pitch and a single row, making it ideal for compact and versatile electronic assemblies.
Constructed with a robust Polyamide 66 housing, the terminal block ensures excellent mechanical stability and resistance to environmental factors. The brass contact material provides low contact resistance of approximately 20 milliohms, supporting reliable electrical connectivity.
Operating at a maximum current of 8 amperes and designed for voltages up to 1.6 kV AC withstand voltage, this terminal block meets demanding power requirements in various industrial and commercial applications. The vertical orientation and screw-type wire connection facilitate straightforward installation and maintenance.
Wurth Elektronik 691348300004 supports a wide wire gauge range, from 30 AWG (0.05 mm²) to 14 AWG (2.08 mm²), which enhances its versatility across different wiring needs. The product is RoHS and lead-free compliant, underscoring its suitability for environmentally conscious manufacturing.
Current rating: 8A for robust performance. Pitch: 3.81 mm to suit standard PCB layouts. Operating temperature range of -40°C to +115°C for broad environmental tolerance. Tin-plated contact surfaces for corrosion resistance.
Steel terminal screws with zinc plating ensure durability.
This pluggable terminal block is widely used in electronics manufacturing, automation systems, industrial control panels, and PCB assemblies. Its compact size (16.12 mm length x 11.1 mm width x 18.3 mm depth) allows for efficient space utilization without compromising performance.
Ideal for applications requiring secure electrical connections with easy plug-and-play capabilities, the Wurth Elektronik WR-TBL Series 691348300004 is a dependable choice in power and signal terminal solutions.
Explore more Pluggable Terminal Blocks and power connectors in the Electronics & Electricals category at EnvMart for comprehensive industrial component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 8 amperes, making it suitable for various industrial and commercial applications.
It supports a maximum working voltage of up to 1.6kV AC, ensuring it can meet demanding power requirements.
The pitch of this model is 3.81 mm, which is suitable for standard PCB layouts.
It features a Polyamide 66 housing and brass contact materials, ensuring optimal conductivity and mechanical stability.
The operating temperature range is from -40°C to +115°C, allowing it to function in various environmental conditions.
This model has 4 contacts, providing multiple connection points for electrical circuits.
The terminal block is designed for vertical orientation, which aids in installation and space efficiency.
It utilizes a screw wire connection method, facilitating secure and easy connections.
The dimensions are 16.12 mm in length, 11.1 mm in width, and 18.3 mm in depth, allowing for efficient space utilization.
Yes, it is RoHS compliant, making it suitable for environmentally conscious manufacturing practices.
The country of origin for this model is India, indicating its manufacturing location.
