STMicroelectronics Power Management Development Kit Evaluation Board 1.8-5.5 V Input, 400 mA Nano-Quiescent STEVAL-1PS02D
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Model | STEVAL-1PS02D |
| For Use With | AUX switch |
| Standards/Approvals | WEEE and RoHS compliant |
| Kit Classification | Evaluation Board |
| Featured Device | ST1PS02DQTR |
| Kit Name | Evaluation Board Based on ST1PS02DQTR 400 mA Nano-Quiescent Synchronous Step-Down Converter with AUX Switch |
Key Features
- Operates from an input voltage range of 1.8 to 5.5 V.
- Delivers up to 400 mA output current with dynamic voltage adjustment.
- Uses ST1PS02DQTR nano-quiescent synchronous step-down converter with enhanced peak current control.
- Includes a controlled load switch to supply subsystems from the same voltage rail.
- Compact design with tiny external components; typical inductance of 2.2 μH.
- Compliant with WEEE and RoHS environmental standards.
- Thin TQFN12 package device measuring 2.0 x 1.7 mm.
- Ideal for power, motor, and robotics development applications.
Product Description
STMicroelectronics STEVAL-1PS02D Power Management Development Kit Evaluation Board enables precise evaluation of a smart synchronous step-down converter designed for advanced power management. The board supports input voltages from 1.8 V up to 5.5 V and delivers a stable output current up to 400 mA with dynamically adjustable output voltage ranging from 1.0 V to 1.35 V. It features the ST1PS02DQTR nano-quiescent synchronous step-down converter which implements enhanced peak current control and advanced circuitry to minimize quiescent current, making it highly efficient for power sensitive applications.
The evaluation board incorporates a controlled load switch to supply subsystems reliably from the same voltage rail, enabling versatile power management configurations. The device is housed in a compact thin TQFN12 package (2.0 x 1.7 mm) and uses tiny external components, featuring a typical inductance of 2.2 μH, contributing to its miniaturized design.
The board complies with WEEE and RoHS standards ensuring environmentally responsible manufacturing and disposal. This development kit is ideal for engineers and developers working in power, motor control, robotics, and other embedded system applications demanding efficient DC/DC conversion and power management solutions.
Operates with input voltage ranging from 1.8 to 5.5 V. Output current capability up to 400 mA. Dynamic output voltage adjustable between 1.0 and 1.35 V. Features enhanced peak current control for improved efficiency. Incorporates controlled load switch for subsystem power supply.
Compact footprint with tiny external components; L = 2.2 μH typical inductance. Utilizes TQFN12 (2.0 x 1.7 mm) thin package device. Compliant with WEEE and RoHS environmental regulations. Suitable for development in power and motor control applications.
This STMicroelectronics Evaluation Board forms an essential tool for design engineers seeking to rapidly prototype and validate power management designs. It accelerates product development in systems requiring high-efficiency DC/DC conversion with low quiescent current consumption.
