Wurth Elektronik 3663 Series Pluggable Terminal Block, 7-Contact, 3.81 mm Pitch, 1 Row, 691366310007

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3663 Series Pluggable Terminal Block, 7-Contact, 3.81 mm Pitch, 1 Row, 691366310007

Name: Wurth Elektronik 3663 Series Pluggable Terminal Block, 7-Contact, 3.81 mm Pitch, 1 Row, 691366310007
Brand: Wurth Elektronik
SKU: 421741
Price: 20.22 USD
Availability: InStock



Category Pluggable Terminal Block Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	2.5kV
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	10A
Length	26.67mm
Depth	19.1mm
Width	10.4mm
Housing Material	Polyamide 66
Series	3663
Number of Rows	1
Pitch	3.81mm
Standards/Approvals	RoHS
Number of Contacts	7
Connector Gender	Male
Minimum Wire Size mm²	0.081mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screw

Key Features

Constructed with durable polyamide 66 housing for enhanced insulation.
Supports a maximum current rating of 10 A for efficient power handling.
Compatible with wire sizes ranging from 28 AWG to 16 AWG.
Features screw wire connection method ensuring secure electrical contacts.
Designed with a horizontal orientation and green color identification.
Compact dimensions measuring 26.67 mm length, 10.4 mm width, and 19.1 mm depth.
Complies with RoHS standards confirming environmentally friendly manufacturing.

Product Description

Wurth Elektronik 691366310007 Pluggable Terminal Block series 3663 is a high-quality connector designed for reliable and secure electrical connections in electronic and electrical systems.

This terminal block features a 7-contact configuration with a 3.81 mm pitch and a single row layout, making it ideal for compact PCB designs where space optimization is critical.

The housing is made from polyamide 66, providing excellent mechanical strength and electrical insulation. With a current rating of 10 A and a voltage rating of 2.5 kV, this terminal block can efficiently handle power requirements in industrial, automation, and commercial electrical applications.

The wire connection is secured by a screw mechanism, compatible with wires from 28 AWG to 16 AWG, ensuring stable and durable connections. Its horizontal orientation and green color coding facilitate easy identification and installation.

Compact dimensions of 26.67 mm length, 10.4 mm width, and 19.1 mm depth enable seamless integration into densely packed electronic assemblies. The product complies with RoHS standards, ensuring it is manufactured with environmentally responsible materials and processes.

Durable polyamide 66 housing for excellent insulation and strength. 10 A maximum current rating for effective power transmission. Supports wire sizes 28 AWG to 16 AWG with screw terminal connection. Green color and horizontal orientation for ease of use.

Compact size suitable for tight PCB layouts. Voltage rating of 2.5 kV for safety and reliability. RoHS compliant ensuring eco-friendly product manufacturing.

This Pluggable Terminal Block is well suited for applications in industrial automation, electronic equipment manufacturing, HVAC systems, power supply units, and general electrical panel assembly.
