onsemi Operational Amplifier SC-70 Package 1.4 MHz Gain Bandwidth 7V NCS2001SQ2T2G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Operational Amplifier SC-70 Package 1.4 MHz Gain Bandwidth 7V NCS2001SQ2T2G

Name: onsemi Operational Amplifier SC-70 Package 1.4 MHz Gain Bandwidth 7V NCS2001SQ2T2G
Brand: onsemi
SKU: 417505
Price: 0.55 USD
Availability: InStock



Category Operational Amplifier Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1mm
Length	2.2mm
Model	NCS2001SQ2T2G
Width	1.35mm
Mount Type	Surface
Series	NCS2001
Output Current	76mA
Maximum Operating Temperature	105°C
Package Type	SC-70
Minimum Operating Temperature	-40°C
Number Of Channels	1
Pin Count	5
Automotive Standard	AEC-Q100
Maximum Supply Voltage	7V
Minimum Supply Voltage	0.9V
GBP - Gain Bandwidth Product	1.4MHz
Input Bias Current	10 pA
Vos - Input Offset Voltage	6 mV
Slew Rate	1.6V/μs

Key Features

Operating voltage range from 0.9 V minimum to 7 V maximum for versatile power supply applications.
Single channel operational amplifier with 5-pin SC-70 surface mount package.
Gain bandwidth product of 1.4 MHz ensures efficient signal amplification in compact electronics.
Low input bias current of 10 pA and input offset voltage of 6 mV for precision performance.
Operating temperature range from -40°C to 105°C, compatible with automotive standards including AEC-Q100 qualification.
Slew rate of 1.6 V/μs allows fast signal response suitable for high-speed analog circuits.
Output current capability of 76 mA supports driving moderate load demands.
No output phase reversal with over-driven input signals enhances signal stability.

Product Description

onsemi NCS2001SQ2T2G is a single-channel operational amplifier packaged in a 5-pin SC-70 surface mount format. Designed for low voltage operation with supply voltage range from 0.9 V up to 7 V, this device offers a gain bandwidth product of 1.4 MHz, making it ideal for compact electronic and automotive applications requiring precise and efficient amplification.

The amplifier features an extremely low input bias current of 10 pA and a maximum input offset voltage of 6 mV, supporting accurate signal processing. It operates reliably over a wide temperature range from -40°C to 105°C and complies with automotive standard AEC-Q100, making it suitable for harsh environmental conditions.

The device boasts a slew rate of 1.6 V/μs for rapid signal changes and an output current of 76 mA to drive typical loads in electronic circuits. Its compact size with dimensions 2.2 mm in length, 1.35 mm in width, and 1 mm in height facilitates integration in space-constrained designs. Additionally, the design ensures no output phase reversal on over-driven inputs, enhancing signal stability and robustness.

Trimmed input offset voltage of 0.5 mV delivers consistent performance critical for precision applications. Typical industrial uses include consumer electronics, automotive sensor interfaces, portable instrumentation, and general-purpose amplification tasks. The SC-70 package supports surface-mount technology for automated PCB assembly, optimizing production efficiency.

This amplifier is part of the NCS2001 series by ON Semiconductor, widely recognized for quality and reliability in industrial and automotive sectors. Operating voltage range from 0.9 V to 7 V. Gain bandwidth product of 1.4 MHz ensures efficient amplification.

Low input bias current and trimmed input offset voltage aids precision. Meets automotive AEC-Q100 standard for harsh environments. Compact SC-70 5-pin package for surface mount PCB integration. Slew rate of 1.6 V/μs supports fast signal response.

Output current of 76 mA suitable for moderate load driving. Wide temperature range from -40°C to 105°C. Explore the extensive range of Operational Amplifiers at EnvMart to suit diverse industrial, automotive, and electronic design needs.
