TRACOPOWER High Performance 15W Dual Output 5V dc 1.5A DC/DC Converter Through Hole THN 15-2421N
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / DC-DC Converters TRACOPOWER THN 15N DC/DC Converter, 5V dc/ 1 |
| Brand | TRACOPOWER |
| Efficiency | 86% |
| Length | 25.4mm |
| Model | THN 15-2421N |
| Depth | 9.9mm |
| Width | 25.4mm |
| Mount Type | Through Hole |
| Series | THN 15N |
| Maximum Operating Temperature | 70°C |
| Package Type | Encapsulated |
| Operating temp. range | - 40°C to +85°C |
| Minimum Operating Temperature | -40°C |
| MTBF | 1670000h |
| Number of outputs | 2 |
| Maximum Output Power | 15W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Output Voltage 1 | 5V dc |
| Output Current 1 | 1.5A |
| Isolation Voltage | 1.6kV dc |
| Output Current 2 | 1500mA |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Output Voltage 2 | -5V dc |
| Smallest encapsulated 15W Converter! Ultra compact size | 1.0 x 1.0 x 0.4 |
Key Features
- Encapsulated shielded metal package measuring 25.4mm x 25.4mm x 9.9mm.
- High efficiency of approximately 86% ensures energy saving performance.
- Isolation voltage rated at 1.6kV dc for enhanced safety.
- Operating temperature range from -40°C to 70°C suitable for harsh environments.
- Output voltages precisely regulated with an adjustment range of ±10%.
- Remote On/Off control functionality for flexible operation.
- Extremely compact size designed to save PCB space in industrial and communication applications.
- Typical applications include mobile equipment, instrumentation, and distributed power architectures.
Product Description
TRACOPOWER THN 15-2421N DC/DC Converter is a robust and ultra-compact 15 Watt power module designed for industrial, communication, and instrumentation applications requiring reliable isolated dual outputs. Manufactured with an encapsulated metal shielded case measuring only 25.4mm x 25.4mm x 9.9mm, this through-hole mounted device provides a high efficiency of 86% and operates within a wide input voltage range of 18 to 36 Volts DC. It delivers a stable 5V DC output at 1.5 Amps current as well as a secondary output of -5V DC, with output voltage adjustment capability of ±10% enabling fine tuning to application needs.
Designed to withstand harsh environments, the converter operates reliably between -40°C to +70°C without derating, and offers 1.6kV DC isolation voltage for enhanced electrical safety. The inclusion of an integrated EN 55032 Class A filter and minimized no-load power consumption positions it as an energy-efficient solution for modern mobile and distributed power systems. Additional features like remote On/Off control and compact shielded design make it ideal where PCB space is critical.
The THN 15-2421N is especially suited for mobile equipment systems, communication devices, and industrial electronics needing precise power conversion. Thanks to its exceptional mean time between failures (MTBF) rating of 1,670,000 hours and quality manufacturing in Taiwan, this converter guarantees reliable long-term operation under demanding conditions.
Encapsulated shielded metal package measuring 25.4mm x 25.4mm x 9.9mm. Wide 2:1 input voltage range from 18V to 36V DC. High efficiency with up to 86% power conversion. Isolation voltage of 1.6kV DC. Operating temperature range between -40°C and 70°C.
Dual output voltages with ±10% adjustment capability. Through-hole mount type for secure PCB fixing. Remote On/Off capability. Low no-load power consumption enhancing energy efficiency. Reliability MTBF of 1,670,000 hours.
This TRACOPOWER converter is ideal for industrial, laboratory, telecommunications, and commercial applications where compact, reliable, and efficient isolated DC power conversion is required. EnvMart offers this model within our extensive range of electronics and power supply components for discerning technology developers and system integrators.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 15W.
It operates within a temperature range of -40°C to +70°C.
The dimensions of the encapsulated shielded metal package are 25.4mm x 25.4mm x 9.9mm.
It has a wide input voltage range from 18V to 36V DC.
This model provides dual output voltages of 5V DC and -5V DC.
The efficiency of this converter is approximately 86%.
Yes, it includes remote On/Off control functionality for flexible operation.
The isolation voltage is rated at 1.6kV DC, enhancing electrical safety.
It is designed for through-hole mounting, ensuring secure PCB fixing.
The MTBF rating is 1,670,000 hours, indicating reliable long-term operation.
It is suitable for mobile equipment, instrumentation, and distributed power architectures.
This model is manufactured in Taiwan.
