Sefram Data Acquisition System 4-Channel 1 Msps 14-bit Resolution Ethernet USB Portable DAS50
Specifications
| Country of Origin | France |
|---|---|
| Resolution | 14 bit |
| Display | 10" TFT LCD screen |
| Brand | Sefram |
| Interface | USB and Ethernet |
| Battery Life | 9h |
| Battery type | Lithium-ion |
| Height | 105mm |
| Length | 295mm |
| Connectivity | Ethernet, USB |
| Model | DAS50 |
| Gross Weight | 2.5kg |
| Width | 210mm |
| Bandwidth | 100kHz |
| Sampling rate | 1Msps |
| Maximum Operating Temperature | 40°C |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Standards/Approvals | CE, IEC 61010 |
| Onboard Memory | 32000MB |
| Lithium-ion battery | 10h continuous operation |
| High safety level for industrial application | CEI 1010 CAT III 600V |
| Optional Printer | 110 mm paper width (factory option) |
Key Features
- Features 4 isolated analogue channels supporting universal inputs from 1mV to 425V RMS.
- Includes 16 logical inputs and optional 2 Pt100/Pt1000 temperature sensor inputs.
- Equipped with Ethernet and USB connectivity for easy remote control and data download.
- Powered by a lithium-ion battery providing over 9 hours of continuous operation.
- Houses 32GB internal memory with onboard 32 M word storage for extensive data recording.
- Supports DC, AC+DC RMS voltage measurement and frequency, thermocouple sensing.
- Includes Power Analysis functionality for single-phase and three-phase electrical networks.
- High safety standard CEI 1010 CAT III 600V certified for industrial applications.
Product Description
Sefram DAS50 Data Acquisition System 4-Channel, model DAS50, delivers precise high-speed data logging suitable for R&D, diagnostic, maintenance and industrial monitoring applications. This standalone, portable, battery-operated instrument supports 1 Msps sampling rate at 14-bit resolution, ensuring accurate capture of electrical parameters with a bandwidth of 100 kHz.
The device incorporates 4 isolated analogue input channels with universal input ranges from 1mV to 425V RMS, plus 16 logical inputs and optional dual Pt100/Pt1000 temperature sensor inputs, making it versatile for various measurement needs. Connectivity is flexible through Ethernet and USB interfaces allowing remote control and easy data downloads.
Powered by a lithium-ion battery, the DAS50 offers more than 9 hours of continuous operation and features a 32GB internal hard disk supplemented with 32 M word onboard memory for extensive data storage. Its 10-inch TFT LCD screen delivers clear visibility of measurements and configurations. The system complies with CE and IEC 61010 safety standards and is rated CEI 1010 CAT III 600V for high industrial safety requirements.
Additional functionalities include DC, AC+DC RMS voltage measurement, frequency analysis, thermocouple support, and a power analysis feature that can monitor parameters on single-phase and three-phase electrical networks accurately.
With options for Wi-Fi connectivity and printer support, the DAS50 is an ideal tool for industrial, laboratory, construction, and manufacturing sectors requiring reliable high-speed data acquisition. Various license-free software packages are available to view and manage recorded data efficiently.
Features 4 isolated analogue input channels. Supports Ethernet and USB connectivity. Battery-operated with lithium-ion battery for long operation. High resolution 14-bit measurement accuracy. 1 Msps sampling rate with 100 kHz bandwidth.
32GB internal memory for extensive data logging. Optional temperature sensor inputs (Pt100/Pt1000). Power analysis capabilities for electrical networks. High industrial safety standards compliance. Optional 110 mm paper width printer available.
Explore more Data Acquisition Systems and related instruments in the Industrial Machines & Instruments category at EnvMart.
