Sefram Data Acquisition System 4-Channel, Ethernet, USB, 1 Msps, 14 bit DAS50
Specifications
| Country of Origin | France |
|---|---|
| Resolution | 14 bit |
| Display | 10" TFT LCD screen |
| Brand | Sefram |
| Interface | USB and Ethernet |
| Battery Life | 9h |
| Battery type | Lithium-ion |
| Height | 105mm |
| Length | 295mm |
| Connectivity | Ethernet, USB |
| Model | DAS50 |
| Gross Weight | 2.5kg |
| Width | 210mm |
| Bandwidth | 100kHz |
| Sampling rate | 1Msps |
| Maximum Operating Temperature | 40°C |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Standards/Approvals | CE, IEC 61010 |
| Onboard Memory | 32000MB |
| Lithium-ion battery | 10h continuous operation |
| High safety level for industrial application | CEI 1010 CAT III 600V |
| Optional Printer | 110 mm paper width (factory option) |
Key Features
- The system offers 4 isolated analogue channels and 16 logical inputs for versatile measurements.
- Supports universal input voltage from 1mV to 425V RMS for DC, AC+DC RMS voltage measurement.
- Equipped with power analysis function for single-phase and three-phase network monitoring.
- Includes a 10-inch TFT LCD screen for easy data visualization and operation.
- Comes with a 32GB internal memory and over 9 hours of battery life with lithium-ion battery.
- Interfaces include USB, Ethernet, and optional Wi-Fi for remote control and data download.
- Available optional printer with 110 mm paper width for on-site printouts.
Product Description
Sefram DAS50 Data Acquisition System DAS50 is a portable, standalone instrument designed for high-speed data recording in industrial, R&D, diagnostic, and maintenance applications. It offers four isolated analogue channels and 16 logical inputs to measure a broad range of electrical parameters reliably.
The system's 14-bit resolution combined with a sampling rate of 1 Msps and 100 kHz bandwidth ensures precise and fast signal acquisition. Its universal input accommodates voltages from 1mV to 425V RMS supporting DC, AC+DC RMS voltage, frequency, and thermocouple measurements. Moreover, a dedicated power analysis function enables comprehensive monitoring of single-phase and three-phase electrical networks.
This Data Acquisition System features a large 10-inch TFT LCD screen for clear visualization and user-friendly operation. Its embedded 32GB internal memory facilitates extensive data logging sessions, supported by a lithium-ion battery offering approximately 9 hours of autonomy for uninterrupted field operation.
The device provides 4 isolated analogue channels and 16 logical channels for versatile inputs. Universal voltage input range from 1mV to 425V RMS enables varied measurement applications. Power analysis function suitable for monitoring single and three-phase networks.
10" TFT LCD screen enhances user interaction and data readability. Large 32GB internal memory supports long-term data logging. Interfaces include USB and Ethernet with optional Wi-Fi connectivity. Lithium-ion battery powers up to 9 hours for mobile use.
Certified with CE and IEC 61010 standards to meet industrial safety requirements. Optional printer with 110 mm paper width available for onsite documentation.
The DAS50 system is ideal for industrial automation, electrical maintenance, laboratory testing, and quality control environments where reliable and precise data acquisition is critical. It supports remote operation and easy data management via multiple connectivity options, enhancing productivity and diagnostic capabilities in demanding applications.
Discover more data acquisition solutions and accessories at EnvMart to complement your measurement and testing operations.
