Abracon 6.144 MHz Crystal Unit ±30 ppm Frequency Tolerance HC-49-US Package Through Hole 2-Pin ABLS-6.144MHZ-B4-T

Abracon ABLS-6.144MHZ-B4-T is a high-quality 6.144 MHz crystal unit engineered for precision frequency control in electronic applications. This crystal unit features a ±30 ppm frequency tolerance and ±50 ppm frequency stability, making it suitable for use in sensitive circuits requiring consistent timing performance.

Encased in a standard HC-49-US through-hole package, this component supports a 2-pin configuration offering straightforward mounting on circuit boards. With a load capacitance of 16 pF and a series resistance of 100 Ω, it ensures optimal oscillation characteristics.

The crystal unit operates effectively within a temperature range of 0°C to 70°C, providing dependable performance under typical operating conditions. Its compact dimensions of 11.5 mm length, 4.7 mm width, and 4.2 mm height contribute to space-efficient PCB layouts.

The ABLS series from Abracon is RoHS compliant, reflecting adherence to environmental regulations and reliability standards expected in modern electronics design. This crystal is commonly used in computing devices, modems, microprocessors, and wireless communication systems where stable and accurate frequency sources are critical.

Features a standard HC-49-US package type for secure installation. Has a 2-pin configuration suitable for various circuit designs. Operates reliably within a temperature range of 0°C to 70°C. Provides a load capacitance of 16 pF, ideal for stable oscillation.

Meets RoHS compliance standards ensuring environmental safety. Offers a series resistance of 100 Ω for efficient frequency stability. Length, width, and height dimensions are 11.5 mm, 4.7 mm, and 4.2 mm respectively. Tape and reel packaging enhances handling and assembly efficiency.

Suitable for industrial, laboratory, and commercial electronic assembly and repair applications, this crystal unit represents a reliable timing component for diverse electronic circuits. Explore more Crystal Units and related components on EnvMart for your electronic project requirements.
