Melexis 3 Axis Surface Position Sensor 4.5 V 5.5 V Digital PWM SOIC 8-Pin MLX90365KDC-ABD-000-RE
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Melexis |
| Response time | 657μs |
| Height | 1.52mm |
| Length | 4.8mm |
| Model | MLX90365KDC-ABD-000-RE |
| Technology | Hall Effect |
| Sensor Type | Position Sensor |
| Width | 3.81mm |
| Mount Type | Surface |
| Series | MLX90365 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number of axis | 3 |
| Interface Type | Digital PWM |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 4.5V |
| Supply Current | 6mA |
| Magnetic Type | Monolithic |
Key Features
- Operates within a supply voltage range of 4.5 V to 5.5 V for flexible power options.
- Employs Hall Effect technology to sense three orthogonal magnetic flux components for absolute position detection.
- Features automotive-grade robustness meeting AEC-Q100 standards and an operating temperature range from -40°C up to 125°C.
- Integrates programmable transfer characteristics and onboard diagnostics including under and over voltage detection.
- Compact SOIC package with dimensions of length 4.8 mm, width 3.81 mm, and height 1.52 mm enables easy surface mounting.
- Low typical supply current of 6 mA and fast response time of 657 μs ensure efficient and timely position sensing.
- Designed for automotive and industrial applications requiring non-contact absolute rotary or linear position measurement.
- RoHS compliant with Malaysia as the country of origin.
Product Description
Melexis MLX90365KDC-ABD-000-RE is a high-performance 3-axis surface position sensor using monolithic Hall Effect technology. Operating between 4.5 and 5.5 volts with digital PWM interface, this sensor IC decodes absolute position by measuring magnetic flux orthogonal and parallel to the IC surface. It is packaged in a compact SOIC 8-pin package measuring 4.8 mm by 3.81 mm by 1.52 mm for surface mount applications.
This position sensor provides a programmable transfer characteristic and selectable output modes allowing analog or pulse width modulated digital signals. It includes integrated onboard diagnostics such as under- and over-voltage detection and thermal offset correction to ensure reliable operation over its automotive temperature range of -40°C to 125°C.
Designed to meet AEC-Q100 automotive standards, the MLX90365 series supports innovative contactless position sensing solutions ideal for automotive and industrial environments. Its low supply current of 6 mA and fast response time enable efficient real-time position feedback.
Applications include absolute rotary and linear position sensing in automotive electronic systems, industrial automation, and robotics. Its robust design and RoHS compliance further make it suitable for global manufacturing compliance requirements.
Operates on hall effect principle with digital PWM output. Monolithic 3-axis sensing capability enables versatile magnetic field detection. Compact SOIC-8 package supports surface mount PCB integration. Automotive temperature range and standards enhance reliability in harsh environments.
Programmable output transfer function and onboard diagnostics support custom configurations. Low current consumption and fast response improve system efficiency. Ideal for automotive, industrial, and motion detection applications.
RoHS compliant with Malaysia as country of origin. Explore more in our Electronics & Electricals Sensors category for advanced Position Sensor ICs by Melexis and other leading manufacturers at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The sensor operates within a supply voltage range of 4.5 V to 5.5 V.
It employs Hall Effect technology to sense three orthogonal magnetic flux components for absolute position detection.
The typical response time is 657 microseconds (μs).
The package dimensions are 4.8 mm in length, 3.81 mm in width, and 1.52 mm in height.
The operating temperature range is from -40°C to 125°C.
It provides a digital PWM output, which allows for programmable transfer characteristics and selectable output modes.
Yes, it meets AEC-Q100 automotive standards, ensuring robustness for automotive applications.
The typical supply current is 6 mA.
It is designed for automotive and industrial applications requiring non-contact absolute rotary or linear position measurement.
The sensor has a pin count of 8.
The country of origin for this product is Malaysia.
It supports surface mounting, making it suitable for PCB integration.
