Panasonic PCB Signal Relay 12V DC Coil 2A DPDT, 60W Switching Power TX2-L-12V
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 8.2mm |
| Length | 15mm |
| Model | TX2-L-12V |
| Width | 7.4mm |
| Mount Type | PCB |
| Contact Material | Gold Plated |
| Series | TX |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 2A |
| Terminal type | Through Hole |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1.44kΩ |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 220V dc |
| Coil Power | 100mW |
| Switching Power | 60W |
| UL recognised, | CSA,:BSI |
Key Features
- The relay operates at a coil voltage of 12V DC with low coil power consumption of 100mW.
- DPDT contact configuration supports switching current up to 2A at 220V DC.
- Compact design with dimensions 15mm length, 7.4mm width, and 8.2mm height.
- Features gold plated contacts for enhanced conductivity and reliability.
- Suitable for PCB mounting with through-hole terminal type for stable installation.
- Operating temperature range from -40°C to 85°C ensures durability in varied environments.
- Meets RoHS compliance, assuring environmentally safe construction.
- High contact capacity and resistance to vibration and shock for industrial applications.
Product Description
Panasonic TX2-L-12V PCB Signal Relay is a high quality signal relay featuring a 12V DC coil and a 2A switching current with DPDT (Double Pole Double Throw) contact configuration. The TX series relay delivers reliable performance for various industrial applications, including communications, measurement, security, automotive, audio visual, medical equipment, and home appliances.
This compact PCB mounted relay measures 15mm in length, 7.4mm in width, and 8.2mm in height, fitting seamlessly into circuit boards with through-hole terminals. Its gold plated contacts ensure excellent conductivity and durability, maintaining low contact resistance of 100mΩ. The relay operates efficiently with a coil power of just 100mW, reducing power consumption in electronic designs.
Designed to withstand harsh environments, the relay has an operating temperature range from -40°C to 85°C and offers an impressive switching power of 60W. The sealed construction allows for automatic washing, making it suitable for rigorous manufacturing and industrial environments. The relay also features a 2 kV breakdown voltage between coil and contact, and delivers excellent resistance against surge, vibration, and shock.
This TX2-L-12V model has certifications including UL recognition, CSA, and BSI, demonstrating compliance with international quality standards. It is RoHS compliant, underscoring its environmentally friendly design. The relay is manufactured in Japan, ensuring top-tier build quality and reliability.
Ideal for use in industrial automation, electronics manufacturing, and embedded system projects, this Panasonic PCB Signal Relay provides dependable switching capability for a wide range of DC voltage applications up to 220V.
The relay operates at a coil voltage of 12V DC with low coil power consumption of 100mW. DPDT contact configuration supports switching current up to 2A at 220V DC. Compact dimensions suit PCB mounting with through-hole terminals.
Gold plated contacts provide excellent conductivity and reliability. Suitable for harsh environments with operating range -40°C to 85°C. Meets RoHS and international safety certifications. Sealed construction enables automatic washing and durability.
Manufactured in Japan to ensure high quality and performance. Explore more high-quality relays and electrical components on EnvMart to suit all industrial and electronic project requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TX2-L-12V relay operates at a coil voltage of 12V DC.
This relay supports a maximum switching current of 2A at 220V DC.
The relay has compact dimensions of 15mm in length, 7.4mm in width, and 8.2mm in height.
The relay features a DPDT (Double Pole Double Throw) contact configuration.
The coil power consumption is 100mW, which helps reduce overall power usage.
The operating temperature range for the relay is from -40°C to 85°C.
It is designed for PCB mounting with a through-hole terminal type for stable installation.
The contact resistance is 100mΩ, ensuring low resistance for reliable operation.
The relay is UL recognized, CSA, and BSI certified, and it meets RoHS compliance.
The contacts of the relay are made from gold plated material, enhancing conductivity and reliability.
The relay has a switching power capacity of 60W.
This relay is manufactured in Japan, ensuring high quality and performance standards.
