MEAN WELL DC/DC Converter 48V DC Output, 48V DC Input 4.2A, 36V Minimum Input, Chassis Mount, 201.6W Power, 1.5kV SD-200C-48
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters MEAN WELL SD-200 DC/DC Converter, 48V dc/, 48V dc |
| Brand | MEAN WELL |
| Efficiency | 86% |
| Length | 215mm |
| Model | SD-200C-48 |
| Depth | 50mm |
| Gross Weight | 1.1kg |
| Width | 50mm |
| Mount Type | Chassis |
| Series | SD-200 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| MTBF | 218200h |
| Number of outputs | 1 |
| Ripple and Noise | 200mV Pk-Pk |
| Maximum Output Power | 201.6W |
| Maximum Input Voltage | 48V dc |
| Standards/Approvals | EN 55022Class B, ENV 50204, EN 61000-4-2 |
| Minimum Input Voltage | 36V |
| Output Voltage 1 | 48V dc |
| Output Current 1 | 4.2A |
| Output Voltage Adjustment Range | 53 V |
| Isolation Voltage | 1.5kV ac |
| Input Ratio | 2:1 |
| Wide 2 | 1 input voltage range |
Key Features
- Supports wide input voltage range from 36V to 48V DC.
- Provides 4.2A output current with adjustable output voltage up to 53V.
- Features 1.5kV AC isolation for enhanced safety and noise reduction.
- Built for high reliability with MTBF of 218,200 hours and 86% efficiency.
- Designed to operate in temperatures from -20°C to 60°C with chassis mount installation.
- Includes short circuit, overload, and overvoltage protection for stable operation.
- Conforms to EN 55022 Class B, ENV 50204, and EN 61000-4-2 EMC standards.
Product Description
MEAN WELL SD-200C-48 DC/DC Converter is a single output regulated and isolated power module designed for industrial, electronic, and automation applications. It supports a wide input voltage range from 36V to 48V DC with an output of stable 48V DC delivering up to 201.6W power, suitable for chassis mount installations.
This converter features a 2:1 input ratio and provides adjustable output voltage capability up to 53V. It is engineered for high reliability with a Mean Time Between Failures (MTBF) of 218,200 hours and an efficiency rating of 86%, ensuring energy-efficient performance.
The SD-200C-48 is designed to operate safely over a temperature range from -20°C min to 60°C max. It provides 1.5kV AC insulation between input and output, protecting sensitive equipment from electrical noise and surges. Protection features include short circuit, overload, and overvoltage safeguards to maintain stable operation under adverse conditions.
Physical dimensions are compact with length, width, and depth measuring 215mm, 50mm, and 50mm respectively, and the chassis mount design ensures easy and secure installation in electronic systems.
Compliance with industrial EMC standards such as EN 55022 Class B, ENV 50204, and EN 61000-4-2 guarantees electromagnetic compatibility and interference resistance for demanding environments.
Wide 2:1 input voltage range from 36V to 48V DC. Regulated isolated output voltage of 48V DC with 201.6W maximum output power. High efficiency at 86% and robust MTBF of 218,200 hours. Short circuit, overload, and overvoltage protection included.
1.5kV isolation voltage ensures noise suppression and safety. Chassis mount type with compact 215 x 50 x 50 mm dimensions. Operating temperature range from -20°C to 60°C suitable for industrial applications. Conformance to EN 55022 Class B and related EMC standards.
This DC/DC Converter is ideal for use in industrial automation, electronics manufacturing, power management systems, and other commercial applications requiring stable 48V DC supply. It delivers reliable performance in challenging electrical environments and is a trusted solution within the MEAN WELL SD-200 series lineup.
Explore more power supply solutions and MEAN WELL products at EnvMart to meet your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a wide input voltage range from 36V to 48V DC.
It delivers a maximum output power of 201.6W.
The converter provides an output current of 4.2A.
The output voltage can be adjusted up to 53V.
The dimensions are 215mm in length, 50mm in width, and 50mm in depth.
It has an efficiency rating of 86%.
This model operates within a temperature range from -20°C to 60°C.
It is designed for chassis mount installation.
It includes short circuit, overload, and overvoltage protection for stable operation.
The isolation voltage is 1.5kV AC, ensuring noise suppression and safety.
It conforms to EN 55022 Class B, ENV 50204, and EN 61000-4-2 standards.
The MTBF is rated at 218,200 hours, indicating high reliability.
