Texas Instruments Operational Amplifier 1 MHz Bandwidth 15V 8-Pin SOIC TL062IDR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | TL062IDR |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | TL062 |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Pin Count | 8 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 20 nA |
| Vos - Input Offset Voltage | 9 mV |
| Slew Rate | 3.5V/μs |
| Input Offset Current | 10 nA |
Key Features
- Dual-channel JFET input amplifier designed for low power consumption.
- Operates with supply voltage ranging from 5V to 15V.
- Input bias current is low at 20 nA for precision applications.
- Offers a slew rate of 3.5 V/μs enabling high speed signal processing.
- Wide operating temperature range from -40°C to 85°C for industrial reliability.
- Compact SOIC surface-mount package with dimensions 4.9mm length, 3.91mm width, and 1.58mm height.
- Maximum input offset voltage of 9 mV and input offset current of 10 nA.
- Part of the TL060 family, known for efficient JFET input operational amplifiers.
Product Description
Texas Instruments TL062IDR Operational Amplifier belongs to the TL060 series of low-power JFET-input op amps optimized for excellent performance with considerably reduced power consumption compared to older TL080 families. The device features dual channels and an 8-pin SOIC surface mount package sized at 4.9 by 3.91 by 1.58 mm height.
This operational amplifier supports supply voltage between 5V minimum and 15V maximum and delivers a gain bandwidth product of 1 MHz. Its low input bias current of 20 nanoamps and low input offset current of 10 nanoamps make it ideal for precision analog circuits. The maximum input offset voltage stands at 9 millivolts, while the slew rate of 3.5 volts per microsecond allows efficient high-frequency response suitable for audio and signal processing applications.
Designed to operate reliably over the temperature range from -40°C to +85°C, this amplifier is robust for industrial and laboratory environments. It does not carry automotive compliance standards but excels in general semiconductor applications, particularly in amplifiers and comparators including audio amplification and signal conditioning tasks.
The compact SOIC package facilitates automated PCB assembly and space-efficient designs. The TL062IDR’s JFET input stage reduces power utilization while maintaining accuracy, making it suitable for battery-powered and portable equipment.
Low power dual-channel JFET input operational amplifier. 1 MHz gain bandwidth product ensuring wide frequency response. Input bias current as low as 20 nA for sensitive circuits. Compact 8-pin SOIC package for surface mount applications.
Operating voltage range of 5V to 15V for diverse power supply environments. Slew rate of 3.5 V/μs for effective signal tracking. Robust temperature rating from -40°C to 85°C for industrial use. Minimal input offset voltage and current ensuring precision.
Suitable for laboratory, industrial, and commercial electronics equipment.
This product is ideal for engineers and designers working in industrial electronics, instrumentation, audio processing, and general analog circuit design. Explore more Operational Amplifiers and related semiconductor components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TL062IDR has a gain bandwidth product of 1 MHz, allowing for wide frequency response suitable for various applications.
This operational amplifier operates with a supply voltage ranging from 5V to 15V, accommodating diverse power supply environments.
The input bias current for the TL062IDR is as low as 20 nA, making it suitable for precision analog circuits.
The maximum input offset voltage of the TL062IDR is 9 mV, ensuring accuracy in signal processing applications.
The slew rate of this model is 3.5 V/μs, which enables effective signal tracking in high-frequency applications.
The dimensions of the TL062IDR are 4.9 mm in length, 3.91 mm in width, and 1.58 mm in height, making it compact for surface mount applications.
This model operates reliably over a temperature range from -40°C to +85°C, suitable for industrial applications.
The TL062IDR is a dual-channel operational amplifier, allowing for multiple signal processing tasks simultaneously.
The TL062IDR comes in an 8-pin SOIC surface mount package, facilitating automated PCB assembly.
The input offset current for the TL062IDR is 10 nA, contributing to its precision in analog applications.
Yes, the low power consumption characteristics of the TL062IDR make it suitable for battery-powered and portable equipment.
The TL062IDR is part of the TL060 series, known for efficient JFET input operational amplifiers designed for low power consumption.
