Releco Timer Relay , 8-Contact, 220 V dc, 150 V ac / 90 V ac, Time Range 0.2 to 30 s & 0.2 to 30 min, 1-Function OFF CT2-A

Releco CT2-A Timer Relay CT2-A model features 8 contacts and is designed for time delay relay operations in industrial automation and electrical control systems. It operates on a DC supply voltage of 220 V and AC supply voltages of 150 V and 90 V, supporting switching voltages up to 400 V. The relay's timing can be accurately adjusted from 0.2 to 30 seconds and 0.2 to 30 minutes by a dial potentiometer enabling fine time settings, suitable for precise control in machinery and process applications.

This relay has one timer function configured as an OFF delay with a 1 change-over (CO) contact setup, allowing for simple integration in control circuits requiring time delay switching. The unit is designed with an 8-pin socket terminal for easy installation and maintenance.

The compact physical size with dimensions 37 mm height, 50 mm length, and 35 mm width makes it suitable for tight panel spaces. It has an IP40 rating, ensuring protection from solid objects and moderate protection against ingress suitable for most industrial environments.

Operating temperature ranges from -25°C to 60°C provide versatility in various environmental conditions. The device meets safety and performance standards including EN 60204-1 and EN 292-2 and is UL and CSA approved for international quality assurance.

The relay supports one timer function with a 1 C/O contact configuration. Switching voltage capacity of up to 400 V and contact current rating of 10 A. Timing adjustment via dial for fine scale control. Enclosure protection IP40 suited for industrial use.

Compact dimensions facilitate panel mounting. Reliable operation within wide temperature range. Compliant with international standards EN 60204-1 and EN 292-2. Manufactured in Sri Lanka with UL and CSA certifications.

This Releco CT2-A timer relay is ideal for industrial automation, electrical machinery, HVAC controls, and other commercial applications requiring precise timing functions. Browse EnvMart's extensive catalog for more Timer Relay options and accessories.
