Nexperia Digital Transistor 500 mA NPN + PNP, 50 V, 6-Pin UMT PBLS1503Y,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.35mm |
| Length | 2.2mm |
| Model | PBLS1503Y,115 |
| Width | 2.2mm |
| Mount Type | Surface |
| Series | PBLS1503Y |
| Maximum Operating Temperature | 150°C |
| Package Type | UMT |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 6 |
| Maximum Collector Emitter Voltage Vceo | 50V |
| Minimum DC Current Gain hFE | 200 |
| Transistor Polarity | NPN + PNP |
| Maximum Emitter Base Voltage VEBO | -6V |
| Maximum Collector Base Voltage VCBO | -15V |
| Maximum Power Dissipation Pd | 200mW |
| Maximum DC Collector Current Idc | 500mA |
| Transistor Configuration | N+P Load Switch |
| Maximum Transition Frequency ft | 280MHz |
Key Features
- The transistor has a 6-pin UMT package suitable for surface mounting.
- It supports a maximum power dissipation of 200 mW.
- The device has a minimum DC current gain (hFE) of 200.
- Operates in a temperature range from -65°C to 150°C for reliable performance.
- Includes a low voltage saturation design optimized for load switching applications.
- Maximum transition frequency is 280 MHz for high-speed switching.
- The transistor integrates bias resistors allowing direct drive from digital circuits.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Nexperia PBLS1503Y,115 digital transistor is a high-performance bipolar transistor combining both NPN and PNP types in a compact 6-pin UMT surface-mount package. It has a maximum DC collector current of 500 mA and collector-emitter voltage rating of 50 V, making it suitable for a variety of industrial and commercial electronic switching applications.
Designed for low voltage saturation (BISS) load switching, these resistive bipolar transistors, also called digital transistors or bias resistor transistors, integrate one or two resistors. The internal resistor network allows these transistors to be driven directly by digital logic outputs without external resistors, improving circuit simplicity and reliability.
This digital transistor series operates reliably over a wide temperature range from -65°C to 150°C and features a minimum DC current gain of 200 and maximum power dissipation of 200 milliwatts. Their fast switching capability with a transition frequency up to 280 MHz supports high-speed industrial electronics, including industrial automation, instrumentation, and communication equipment.
The compact dimensions - 2.2 mm length and width, and 1.35 mm height - fit modern surface mount technology (SMT) standards, helping reduce PCB real estate in densely populated assemblies. It complies with RoHS directives to meet environmental requirements in semiconductor manufacturing.
The device is ideal for digital load switching applications involving moderate current and voltage levels. Package Type: 6-Pin UMT surface mount. Transistor Configuration: NPN + PNP combined load switch. Typical uses include industrial electronics, power control, and digital logic interfacing.
Reliable under harsh temperature conditions, suitable for automotive and industrial environments (automotive standard not certified). Explore our extensive semiconductor catalog for complementary Digital Transistors and bipolar transistor solutions at EnvMart for your industrial and laboratory requirements.
