Amphenol Communications Solutions EconoStik Series Vertical Through Hole Pin Header, 36 Contacts, 2.54 mm 10129378-936001BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 110V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 10129378-936001BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU RoHS, REACH/SvHC |
| Contact Plating | Gold |
| Number of Contacts | 36 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
Key Features
- Features a 2.54 mm pitch suitable for standard PCB layouts.
- Contains 36 male contacts in a single row for robust connectivity.
- Gold plating provides enhanced conductivity and durability.
- Constructed with high-temperature thermoplastic housing for reliability under stress.
- Supports a maximum current of 3A and voltage rating of 110V.
- Designed with solder termination type and through hole mount for PCB integration.
- Operating temperature ranges from -55°C to 105°C, ensuring performance in extreme environments.
- Tail pin length of 3.05 mm and mating pin length of 5.84 mm enable secure connections.
Product Description
Amphenol Communications Solutions 10129378-936001BLF EconoStik Series Vertical Through Hole Pin Header features 36 male contacts arranged in a single vertical row with 2.54 mm pitch. Made for reliable board-to-board connectivity in electronic devices, it supports industrial control, test equipment, metering, POS machines, set-top boxes, surveillance, and vending machines.
The connector uses high-temperature thermoplastic housing and gold plating of 1 μin on contacts and tails, providing durability and conductivity. Tail pins length is 3.05 mm while mating pins extend 5.84 mm ensuring secure solder connections through the PCB.
This pin header supports a continuous current of 3 amperes at 110 volts and operates reliably in temperatures from -55°C to 105°C. Its unshrouded design allows for easy mating and customization, with polarizations available on request.
Environmental compliance includes CHINA RoHS, EU RoHS, and REACH/SvHC, confirming its suitability in environmentally sensitive applications. The product is suitable for industrial manufacturing, electronic assembly, and HVAC control systems.
Features a 2.54 mm pitch for standard PCB compatibility. 36 contacts in a single vertical row. Gold-plated copper alloy contacts for high conductivity. High-temperature thermoplastic housing ensures mechanical strength. Through hole mount and solder termination for secure PCB installation.
Wide operating temperature range from -55°C to 105°C. Supports 3A current at 110V voltage rating. Complies with international environmental standards. Discover more Amphenol Communications Solutions products and explore our extensive catalog of PCB connectors and related electronic components on EnvMart.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a maximum current of 3A and a voltage rating of 110V.
The pitch size is 2.54 mm, suitable for standard PCB layouts.
It features a high-temperature thermoplastic housing and gold-plated copper alloy contacts for enhanced conductivity.
The operating temperature ranges from -55°C to 105°C, allowing it to perform in extreme environments.
This model has 36 male contacts arranged in a single vertical row.
It uses a solder termination type for secure connections.
The tail pin length is 3.05 mm, which helps ensure a secure solder connection through the PCB.
Yes, it is designed for reliable board-to-board connectivity in various industrial applications, including control systems and test equipment.
It complies with CHINA RoHS, EU RoHS, and REACH/SvHC standards, making it suitable for environmentally sensitive applications.
The mating pin length is 5.84 mm, facilitating secure connections.
It supports through hole mounting for PCB integration.
The orientation is vertical, allowing for efficient space utilization on PCBs.
