Texas Instruments Operational Amplifier, LM224D, 1.2 MHz Gain Bandwidth, 14-Pin SOIC, 5V to 30V Supply, Surface Mount LM224D

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Operational Amplifier, LM224D, 1.2 MHz Gain Bandwidth, 14-Pin SOIC, 5V to 30V Supply, Surface Mount LM224D

Name: Texas Instruments Operational Amplifier, LM224D, 1.2 MHz Gain Bandwidth, 14-Pin SOIC, 5V to 30V Supply, Surface Mount LM224D
Brand: Texas Instruments
SKU: 390255
Price: 20.22 USD
Availability: InStock



Category Operational Amplifier Brand Texas Instruments Condition New

Specifications

Country of Origin	Malaysia
Brand	Texas Instruments
Height	1.58mm
Length	8.65mm
Model	LM224D
Width	3.91mm
Mount Type	Surface
Series	LM224
Output Current	-10mA
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-25°C
Number Of Channels	4
Standards/Approvals	RoHS
Pin Count	14
Maximum Supply Voltage	30V
Minimum Supply Voltage	5V
GBP - Gain Bandwidth Product	1.2MHz
Input Bias Current	-300 nA
Vos - Input Offset Voltage	7 mV
Slew Rate	0.5V/μs
Input Offset Current	100 nA

Key Features

Operates with a supply voltage range from 5V to 30V.
Features four channels in a single package with a 14-pin SOIC surface mount design.
Low input bias current of -300 nA and input offset voltage of 7 mV ensure precision performance.
Slew rate of 0.5 V/μs suitable for various amplifier applications.
Operating temperature range from -25°C to 85°C for versatile industrial use.
Complies with RoHS standards for environmental compliance.
Compact dimensions of 8.65 mm length, 3.91 mm width, and 1.58 mm height for board space efficiency.
Output current capability of -10 mA for moderate drive applications.

Product Description

Texas Instruments LM224D operational amplifier is a general-purpose quad operational amplifier offering a gain bandwidth product of 1.2 MHz. It is supplied in a 14-pin SOIC surface mount package, making it suitable for compact PCB designs.

This device operates across a supply voltage range between 5V and 30V and supports an extensive operating temperature range from -25°C to 85°C, enabling reliable operation in industrial, commercial, and laboratory environments.

The LM224D features low input bias current (-300 nA), low input offset voltage (7 mV), and a moderate slew rate (0.5 V/μs), facilitating accurate signal amplification for audio, sensor conditioning, and control systems.

Its compact package dimensions (8.65 mm length, 3.91 mm width, 1.58 mm height) provide high-density circuit integration. The device complies with RoHS environmental standards, ensuring sustainability and reduced hazardous substances.

This amplifier supports output current up to -10 mA, catering to moderate load driving needs in analog signal processing applications. Wide supply voltage range from 5V to 30V allows flexibility in power design. Four channels in one device optimize space and cost in multi-signal systems.

Low input current and offset voltage uphold high precision. Robust operating temperature range suitable for various environments. RoHS compliant for environmental safety.

The Texas Instruments LM224D is ideal for use in industrial control systems, audio devices, measurement equipment, and laboratory instrumentation. Its proven reliability and standard package offer design ease and consistent performance.
