Murata Ferrite Bead 0.5 mm Surface Mount 0402, 10 Ω Impedance at 100 MHz BLM15AG100SN1D

Murata BLM15AG100SN1D is a 0402 size surface mount ferrite bead engineered to provide 10 ohms impedance at 100 MHz, making it highly effective for suppressing electromagnetic noise in electronic circuits. This ferrite bead features a compact design with dimensions of 1 mm length, 0.5 mm height, and 0.5 mm depth, suitable for dense PCB layouts.

The ferrite material construction allows it to behave nearly as a resistor at noise frequencies, minimizing resonance and preserving signal integrity. Its nickel barrier external electrodes offer excellent solder heat resistance, ensuring durability during PCB assembly processes.

Rated to carry up to 1 ampere of current, with a maximum DC resistance of just 0.05 ohms, it maintains low insertion loss while providing effective noise attenuation. The operating temperature range from -55°C to 125°C makes it reliable across various environmental conditions.

Murata's BLM15A series beads are designed for general-purpose EMI noise suppression, especially beneficial for circuits with unstable ground lines as they do not require grounding. They efficiently suppress noise in the frequency range from 30 MHz to several hundred MHz.

Compliant with RoHS and REACH regulations, this component supports environmentally responsible manufacturing. The product is supplied on tape and reel packaging, optimized for automated manufacturing equipment.

Surface mount 0402 package for compact and efficient board design. Provides 10 Ω impedance at 100 MHz to reduce EMI effectively. Current rating of 1A supporting moderate power applications. Wide temperature range for reliable operation in harsh conditions.

Low DC resistance ensures minimal signal degradation. Nickel barrier electrodes offer robust solder heat resistance. Ideal for general purpose EMI suppression without ground connection. RoHS and REACH compliant for environmental safety.

Packaged in tape and reel format for automated PCB assembly.

This Murata ferrite bead is suitable for industrial electronic manufacturing, telecommunications, computing devices, automotive electronics, and consumer electronics applications requiring efficient EMI suppression. Explore more components in the Ferrite Beads category at EnvMart for complementary solutions.
