Wurth Elektronik WE-LHMI 5030 Shielded Wirewound Surface Mount Inductor with Powdered Iron Core 5.6 μH ±20% 3.3A 74437336056
Specifications
| Country of Origin | India |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2.8mm |
| Length | 5.2mm |
| Depth | 5.2mm |
| Packaging | Tape & Reel |
| Series | WE-LHMI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Powdered Iron |
| Inductance | 5.6μH |
| Standards/Approvals | JEDEC JS709B, IEC 61249-2-21, REACH, RoHS |
| Package/Case | 5030 |
| Maximum DC Current | 3.3A |
| Pin Count | 2 |
| Maximum DC Resistance | 63mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 22MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Constructed with a powdered iron core to provide magnetically shielded performance.
- Compact 5030 package size with dimensions 5.2mm length, 2.8mm height, and 5.2mm depth.
- Operates within a temperature range of -40°C to 125°C and meets automotive AEC-Q200 standards.
- Features low maximum DC resistance of 63mΩ ensuring efficiency.
- Designed as a surface mount device with 2 pins and molded construction.
- Suitable for high transient current spikes applications with no acoustic noise and no leakage field.
- Compliance with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards.
- Ideal for DC-DC converters, POL converters, FPGA power supplies, and portable power devices.
Product Description
Wurth Elektronik 74437336056 WE-LHMI 5030 shielded wirewound surface mount inductor is a high-performance SMD power inductor featuring a powdered iron core. It offers an inductance of 5.6 μH with a tolerance of ±20% and is rated for a maximum DC current of 3.3 A, making it suitable for demanding electronic applications.
The compact 5030 package measures 5.2 mm in length, 2.8 mm in height, and 5.2 mm in depth, facilitating ease of integration on modern PCBs. Its robust construction ensures operation within -40°C to 125°C, meeting stringent automotive standard AEC-Q200 requirements. The device incorporates a magnetic shield to minimize leakage fields and acoustic noise, enhancing overall system stability and longevity.
With a maximum DC resistance of just 63mΩ and a maximum self-resonant frequency of 22 MHz, this inductor is designed to operate efficiently in high transient current environments. The 2-pin surface mount termination and wirewound construction provide reliability and consistent performance.
The WE-LHMI series is ideal for industrial and electronic applications such as DC-DC converters for high current power supplies, field programmable gate arrays (FPGA), POL converters, portable power equipment including PDAs and digital cameras, as well as mainboards and graphic cards. Its compliance with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards assures quality and environmental safety.
Constructed with a powdered iron core to provide magnetically shielded inductance. Compact 5030 package size suitable for space-constrained PCBs. Designed for high transient current spikes with no acoustic noise or leakage fields.
Supports a maximum DC current of 3.3 A with low DC resistance. Meets automotive-grade AEC-Q200 and international standards. Wide operating temperature range from -40°C to 125°C. Surface mount termination with 2 pins for automated PCB assembly.
Applicable in diverse industrial, automotive, and portable electronics.
Explore more electronic components and Surface Mount Inductors from Wurth Elektronik and other leading brands on EnvMart to find quality products tailored to your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 5.6 μH with a tolerance of ±20%.
It is rated for a maximum DC current of 3.3 A, making it suitable for high current applications.
The dimensions of this unit are 5.2 mm in length, 2.8 mm in height, and 5.2 mm in depth.
The maximum operating temperature is 125°C, allowing it to function in high-temperature environments.
This inductor features a powdered iron core, which provides magnetically shielded performance.
It complies with JEDEC JS709B, IEC 61249-2-21, REACH, and RoHS standards, ensuring quality and environmental safety.
The termination style is surface mount with 2 pins, designed for automated PCB assembly.
The maximum DC resistance is 63 mΩ, which contributes to its efficiency in operation.
The maximum self-resonant frequency is 22 MHz, suitable for high-frequency applications.
This model is ideal for applications such as DC-DC converters, POL converters, FPGA power supplies, and portable power devices.
The minimum operating temperature is -40°C, allowing it to function in low-temperature environments.
