Bourns Wirewound Shielded Surface Mount Inductor 10μH ±20% 3.5A 7028 Package SRP7028A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Bourns |
| Height | 2.8mm |
| Length | 7.3mm |
| Model | SRP7028A |
| Depth | 6.6mm |
| Packaging | Reel |
| Series | SRP7028A |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Carbonyl Powder |
| Inductance | 10μH |
| Standards/Approvals | RoHS |
| Package/Case | 7028 |
| Maximum DC Current | 3.5A |
| Pin Count | 2 |
| Maximum DC Resistance | 85mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 14MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a Carbonyl powder core for high performance.
- Complies with AEC-Q200 automotive standard for reliability.
- Metal shielded construction minimizes electromagnetic interference.
- Compact 7028 case size with length 7.3 mm, height 2.8 mm, and depth 6.6 mm.
- RoHS compliant and halogen free for environmental safety.
- Maximum DC resistance of 85 mΩ ensures low power loss.
- Maximum operating temperature is 150°C for durable use.
- Rated self-resonant frequency is 14 MHz, suitable for high-frequency applications.
Product Description
Bourns SRP7028A is a wirewound shielded surface mount inductor with a Carbonyl powder core, designed for automotive and industrial electronic applications. It provides an inductance of 10μH with a tolerance of ±20% and supports a maximum DC current of 3.5A.
The inductor features a compact 7028 package case measuring 7.3 mm in length, 2.8 mm in height, and 6.6 mm in depth, making it suitable for space-constrained PCB layouts. It offers magnetic shielding to reduce electromagnetic interference and operates reliably in temperatures ranging from -40°C to 150°C.
This component meets the rigorous AEC-Q200 automotive standard and is RoHS compliant, ensuring it adheres to environmental and safety regulations. The maximum DC resistance of 85mΩ minimizes power losses, and its maximum self-resonant frequency of 14 MHz supports high-frequency applications.
Features a Carbonyl powder core for stable inductance. High saturation current capacity ensures performance under heavy loads. Magnetically shielded construction reduces EMI in sensitive circuits. Compliant with automotive quality standards facilitating use in vehicle electronics.
Compatible for use in DC-DC converters and power supply filtering systems. Compact surface mount design simplifies automated assembly processes. Halogen free and environmentally friendly manufacturing. Provides consistent quality factor Q minimum of 20 for improved efficiency.
This inductor from Bourns is an excellent choice for industrial, automotive, and power management applications requiring reliable and space-efficient inductors. Explore more Surface Mount Inductors at EnvMart for your electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The SRP7028A inductor has an inductance value of 10μH with a tolerance of ±20%.
This model supports a maximum DC current of 3.5A.
The dimensions of the SRP7028A are 7.3 mm in length, 2.8 mm in height, and 6.6 mm in depth.
The maximum operating temperature for the SRP7028A is 150°C.
The rated self-resonant frequency of this inductor is 14 MHz, making it suitable for high-frequency applications.
It features a Carbonyl powder core, which contributes to its high performance.
Yes, it complies with the AEC-Q200 automotive standard for reliability.
The maximum DC resistance of the SRP7028A is 85 mΩ, which helps minimize power loss.
This inductor features a wirewound construction with magnetic shielding to reduce electromagnetic interference.
The minimum quality factor Q for this model is 20, which contributes to improved efficiency.
The termination style for this inductor is solder, suitable for surface mount applications.
The SRP7028A is manufactured in India.
