Bourns Shielded Wirewound Surface Mount Inductor 4.7 μH 1.4 A Idc 40 MHz SRN4026

Bourns SRN4026 Shielded Wirewound Surface Mount Inductor is a miniature power inductor designed with a semi-magnetically shielded construction and a ferrite core. It provides an inductance value of 4.7 μH with a tolerance of ±20% and supports a maximum DC current of 1.4 A. The device is housed in a compact 4026 package with dimensions 4 mm length, 2.5 mm height, and 4 mm depth, ideal for space-sensitive applications.

This inductor is constructed with wirewound technology, ensuring enhanced electromagnetic interference (EMI) shielding and excellent performance in switching power supply circuits such as DC/DC converters. It operates reliably within a wide temperature range from -40°C to 125°C, making it suitable for industrial, automotive, and consumer electronics environments.

The maximum DC resistance value of 48 mΩ contributes to efficient power delivery with minimal loss. The termination style employs solder pads, facilitating easy surface mounting on printed circuit boards (PCBs) in automated production. The component meets RoHS environmental compliance for safer disposal and environmental impact reduction.

The maximum self-resonant frequency of 40 MHz with a minimum quality factor (Q) of 9 ensures effective filtering and noise suppression, critical in high-frequency circuits. Typical applications include use in notebook computers, digital video cameras, hard disk drives (HDDs), cell phones, televisions, and LCD displays.

Semi-magnetically shielded wirewound design minimizes EMI interference. Compact 4026 package for space-saving applications. Ferrite core material provides magnetic stability and durability. Wide operating temperature range supports diverse environments.

RoHS compliant for environmental safety and regulatory compliance. Solder termination supports standard surface mount assembly. Suitable for DC/DC converters and portable electronics. High quality factor and self-resonant frequency optimize performance for high-frequency applications.

Efficient current handling with low resistance losses.

This Bourns SRN4026 inductor is a reliable choice for designers seeking high-quality surface mount inductors capable of stable performance in demanding industrial and consumer electronics. Explore more Bourns components and Surface Mount Inductors in the Electronics & Electricals category at EnvMart for your next innovative project.
