Eaton xEffect Miniature Circuit Breaker, 3-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278889 FAZ-D5/3

Free Delivery in India | Lowest Global Shipping Charges

Eaton xEffect Miniature Circuit Breaker, 3-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278889 FAZ-D5/3

Name: Eaton xEffect Miniature Circuit Breaker, 3-Pole, 5A, Type D, 415V AC, 10 kA Breaking Capacity 278889 FAZ-D5/3
Brand: Eaton
SKU: 381424
Price: 178.15 USD
Availability: InStock



Category Miniature Circuit Breaker Brand Eaton Condition New

Specifications

Country of Origin	India
Range	xEffect
Brand	Eaton
Model	278889 FAZ-D5/3
Depth	73mm
IP Rating	IP20
Width	85mm
Mount Type	DIN Rail
Current Rating	5A
Series	xEffect
Breaking Capacity	10kA
Number of Poles	3
Rated AC Voltage	415V ac
Tripping Characteristics	Type D
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Instantaneous

Key Features

This circuit breaker is designed for DIN rail mounting in control panel applications.
The FAZ series circuit breakers feature thermal-magnetic trip mechanisms for enhanced protection.
The toggle switch allows sealing in both ON and OFF positions with trip-free function for safety.
Compact dimensions of 85mm width and 73mm depth support space-saving installations.
IP20 rated for protection against solid objects with no water ingress protection.
Red and green indicators show contact positions clearly.
Rated for short circuit interruption to minimize let-through energy damage.
Suitable for supplementary protection applications across industrial and commercial sectors.

Product Description

Eaton 278889 FAZ-D5/3 Miniature Circuit Breaker is a 3-pole device designed to provide reliable and safe overcurrent protection in electrical circuits. Operating at 415V AC with a current rating of 5A, it features Type D thermal-magnetic tripping characteristics and a breaking capacity of 10 kA. This DIN rail-mountable circuit breaker is ideal for use in control panels and diverse industrial environments.

The FAZ series from Eaton offers enhanced safety with a current limiting design that reduces let-through energy during short circuits, preventing damage to connected equipment. The device's toggle switch supports a trip-free function and can be sealed in both ON and OFF positions for tamper resistance. The compact form factor with dimensions of 85mm width and 73mm depth facilitates easy installation in confined spaces.

IP20 ingress protection ensures safety against solid foreign objects, while the thermal-magnetic trip mechanism guarantees six levels of overcurrent protection for consistent operation. Visual indication of contact position via red and green lights aids in quick status verification.

This miniature circuit breaker is suitable for supplementary protection in industrial, commercial, and building automation applications requiring dependable circuit interruption and control. Eaton, previously known as Moeller, manufactures this product adhering to high standards of quality and reliability.

This circuit breaker is designed for DIN rail mounting in control panel applications. The FAZ series circuit breakers feature thermal-magnetic trip mechanisms for enhanced protection. The toggle switch allows sealing in both ON and OFF positions with trip-free function for safety.

Compact dimensions of 85mm width and 73mm depth support space-saving installations. IP20 rated for protection against solid objects with no water ingress protection. Red and green indicators show contact positions clearly.

Rated for short circuit interruption to minimize let-through energy damage. Suitable for supplementary protection applications across industrial and commercial sectors. Explore the Eaton xEffect Miniature Circuit Breaker range at EnvMart for industrial, electrical, and automation protection solutions.
