Eaton xEffect Miniature Circuit Breaker 2-Pole 40A Type C 415V AC 10kA Breaking Capacity 102176 FAZ-C40/2-NA

Eaton 102176 FAZ-C40/2-NA Miniature Circuit Breaker is a 2-pole device rated at 40 amps with Type C tripping characteristics. It operates at a rated AC voltage of 415V and has a high breaking capacity of 10kA. This breaker is designed for DIN rail mounting, making it ideal for integration in control panels across industrial, commercial, and residential electrical installations.

The product features a robust thermal magnetic tripping mechanism that ensures instant response to overcurrent events, providing safe and reliable circuit interruption. The toggle switch actuator can be locked in either the ON or OFF position to prevent unauthorized switching and enhances operational safety.

The breaker’s current limiting design effectively reduces let-through energy during short circuits, protecting downstream circuit components from damage. With six levels of thermal-magnetic protection, it ensures dependable performance against overloads and short circuits. Its IP20 ingress protection rating provides basic protection against access to hazardous parts and deposit of solid foreign objects.

Compact dimensions of 105mm width and 76mm depth support space-efficient installation on standard DIN rails. The use of screw-type terminals allows secure and reliable electrical connections. Eaton’s xEffect FAZ series circuit breakers are engineered to ensure consistent performance under demanding electrical environments.

Designed for control panel applications with DIN rail mount compatibility. High breaking capacity of 10kA for effective short circuit interruption. Type C trip characteristic suitable for general use in residential and commercial circuits.

Toggle switch actuator with lockable ON/OFF positions enhances safety. Robust thermal magnetic trip mechanism for overload and short circuit protection. IP20 rated for protection against solid object ingress. Compact size for easy integration in electrical panels.

Screw terminal connection ensures secure wiring. Manufactured in Romania adhering to quality standards.

This Eaton xEffect Miniature Circuit Breaker is suitable for various industrial, HVAC, manufacturing, and electrical distribution applications. It delivers reliable protection and prolongs the lifespan of electrical equipment by tripping fast under fault conditions.
