Phoenix Contact SMSTB 2.5/4-ST-5.08 Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 320V, Polyamide 1826306

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact SMSTB 2.5/4-ST-5.08 Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 320V, Polyamide 1826306

Name: Phoenix Contact SMSTB 2.5/4-ST-5.08 Series Pluggable Terminal Block, 4-Contact, 5.08 mm Pitch, 320V, Polyamide 1826306
Brand: PHOENIX CONTACT
SKU: 373746
Price: 20.22 USD
Availability: InStock



Category Pluggable Terminal Block Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Germany
Voltage	320V
Brand	Phoenix Contact
Colour	Green
Orientation	Straight
Current	12A
Length	20.32mm
Model	1826306
Depth	15.5mm
Width	25.6mm
Housing Material	Polyamide
Series	SMSTB 2.5/4-ST-5.08
Number of Rows	1
Pitch	5.08mm
Number of Contacts	4
Connector Gender	Female
Minimum Wire Size mm²	0.2mm²
Maximum Wire Size mm²	2.5mm²
Minimum Wire Size AWG	24AWG
Maximum Wire Size AWG	12AWG
Wire Connection Method	Screw Connection with Tension Sleeve
Optimized for tight installation situations	operation and conductor connection from one direction

Key Features

The product features a polyamide housing that ensures durability and stability in electrical installations.
Rated for a current of 12A and voltage of up to 320V for robust performance.
Supports wire sizes from 0.2 mm² to 2.5 mm² and AWG 24 to AWG 12, offering versatile connectivity options.
Utilizes screw connection with a tension sleeve for secure and optimal conductor retention.
Optimized for tight installation spaces with straight orientation for easy wiring access.
Available in green color ensuring easy identification in electrical assemblies.
Compact dimensions with a width of 25.6 mm, length of 20.32 mm, and depth of 15.5 mm.

Product Description

Phoenix Contact 1826306 SMSTB 2.5/4-ST-5.08 Series pluggable terminal block is engineered for industrial and electrical applications requiring secure and efficient connection solutions. This 4-contact, 1-row terminal block has a 5.08 mm pitch and supports a current rating of 12A and voltage rating of 320V, making it suitable for a wide range of control and power distribution systems.

Constructed with a robust polyamide housing, the terminal block offers excellent mechanical durability and chemical resistance, suitable for demanding environments. The screw connection with tension sleeve allows for reliable conductor retention and minimal temperature rise during operation.

The terminal block accommodates wire sizes from 0.2 mm² to 2.5 mm² (AWG 24 to AWG 12), enabling flexible wiring options. Its straight orientation and compact design optimize space in tight installation settings and simplify installation and maintenance tasks.

This component is ideal for use in industrial automation, control panels, power supply equipment, and instrumentation systems, providing consistent, high-quality electrical connections.

The polyamide housing ensures durability and stability for long-term use. Current rating of 12A accommodates various power requirements. Voltage rating up to 320V supports diverse electrical systems. Wire connection via screw method with tension sleeve enhances conductor retention.

Compact dimensions optimize space in electrical assemblies. Green color coding allows easy identification of terminal blocks. Supports 4 contact points for multiple circuit connections. The Phoenix Contact SMSTB 2.5/4-ST-5.08 offers a reliable and versatile solution compatible with a range of industrial and commercial electrical applications.
