Wurth Elektronik 2.4 V Red LED 0603 Surface Mount High Brightness WL-SMCW 150060RS75000

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 2.4 V Red LED 0603 Surface Mount High Brightness WL-SMCW 150060RS75000

Name: Wurth Elektronik 2.4 V Red LED 0603 Surface Mount High Brightness WL-SMCW 150060RS75000
Brand: Wurth Elektronik
SKU: 376351
Price: 0.14 USD
Availability: InStock



Category LED Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Model	150060RS75000
Packaging	Tape & Reel
Mount Type	Surface
Series	WL-SMCW
Maximum forward current	30mA
Viewing angle	140 °
Package Type	0603
Standards/Approvals	RoHS
LED Colour	Red
Dominant Wavelength	625nm
Forward Voltage	2.4V
Number of Pins	2
LED Luminosity	250 mcd
Maximum Power Dissipation	72mW
Lens Dimensions	1.6 x 0.8 x 0.7 mm
Lens Shape	Rectangular
Industry-standard packages	0603 / 0805 / 1206

Key Features

The LED features a water-clear rectangular lens with a top-view configuration.
It has a maximum forward current of 30mA and maximum power dissipation of 72mW.
The LED luminosity is rated at 250mcd with a wide 140° viewing angle.
The compact lens dimensions are 1.6 x 0.8 x 0.7 mm, suitable for dense PCB layouts.
This component is RoHS compliant and manufactured in China.
It is ideal for backlighting, indicators, message boards, displays, and optical signaling applications.
Available in tape and reel packaging for automated assembly processes.

Product Description

Wurth Elektronik 150060RS75000 is a single colour red LED designed with an industry-standard 0603 surface mount package and water-clear rectangular lens. Operating at a forward voltage of 2.4 V and maximum forward current of 30mA, this LED achieves a luminous intensity of 250mcd with a wide 140° viewing angle. Its ultra-compact lens dimensions of 1.6 x 0.8 x 0.7 mm make it perfect for applications requiring high brightness in a small footprint.

This LED series belongs to the WL-SMCW family, known for low power consumption, high reliability, and long service life. The component is RoHS compliant and manufactured in China.

Applications for the Wurth Elektronik 150060RS75000 include backlighting for portable and mobile devices, switch and indicator illumination, message boards, optical indicators, toys, and general lighting.

Features of this LED include water-clear lens, tape and reel packaging for efficient manufacturing, and versatile surface mount capability. Water-clear rectangular top-view lens for enhanced brightness. Wide 140° viewing angle for broad illumination coverage.

Maximum forward current rating of 30mA ensures safe operation. Compact 0603 package dimensions support dense PCB designs. RoHS compliant, supporting environmental standards. Tape and reel packaging optimized for automated production.

Reliable performance with long service life suited for industrial and commercial uses.

This product fits into the LED category within electronics components, suitable for industrial, laboratory, manufacturing, and commercial usage. Browse more Wurth Elektronik LEDs and related LED components at EnvMart.
