Burkert 2 Port Normally Closed Brass Solenoid Valve, 10mm Orifice, 230V AC, 10 bar Max Pressure, IP65 Rated 221601
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Burkert |
| Body Material | Brass |
| Maximum Operating Pressure | 10 bar |
| Model | 221601 |
| Series | 221 |
| Number Of Ports | 2 |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -10°C |
| Orifice Diameter | 10mm |
| Supply Voltage | 230V ac |
| Hazardous Area Certification | explosion protection Ex-i (intrinsically safe) |
| Standards/Approvals | IP65 |
| Inlet Port Size | G3/8 |
| Default Valve Position | NC |
| Flow Factor Kv | 1.9m³/h |
| RS PRO Solenoid Valve, 2 Port, NC, 220V G3/8, G3/8RS Stock No. | 255-4162Brand: RS PRO |
Key Features
- The valve features a 10 mm orifice diameter enabling efficient flow control.
- It has a maximum operating pressure of 10 bar suitable for diverse industrial use.
- Constructed from brass, the valve offers durability and corrosion resistance.
- The valve operates within a temperature range of -10°C to 80°C.
- Equipped with IP65 protection rating ensures reliable operation in industrial environments.
- Servo assist function enhances smooth and quiet valve operation without water hammer.
- The valve is explosion protection Ex-i certified for intrinsically safe hazardous areas.
- It is ideal for use with water, inert gases, compressed air, vacuum systems, heating, refrigeration, water treatment, and swimming pool technology.
Product Description
Burkert 221601 is a high-quality 2 port normally closed brass solenoid valve operating at 230V AC with a 10 mm orifice diameter and maximum pressure of 10 bar. This valve is engineered for precise fluid and gas control in industrial, water treatment, HVAC, compressed air, vacuum, and swimming pool applications.
The valve body is manufactured from brass, ensuring excellent durability and resistance to corrosion. It functions over a temperature range from -10°C to 80°C and includes a servo assist mechanism that provides smooth operation and minimizes water hammer effects. The sealed coil design enhances reliability in harsh environments.
The valve features IP65 ingress protection, making it suitable for industrial and mechanical fluid power systems where robust protection is required. It carries explosion protection certification Ex-i for intrinsically safe operation in hazardous areas, providing added safety for critical applications.
With a flow factor Kv of 1.9 m³/h and compact dimensions, it supports flexible installation in various industrial setups, including heating and refrigeration systems and treatment plants. Due to the valve's internal complexity, it is recommended for use only with clean and neutral media.
The product meets strict German manufacturing standards, reflecting superior quality and long service life. The valve is designed to open without differential pressure, with a minimum 0.5 bar pressure differential required for full opening and a response time between 0.1 to 4 seconds, ensuring responsive control.
The valve is suited for compressed air and vacuum systems, water treatment processes, heating and refrigeration, and swimming pool technology. Its compact size allows installation in limited spaces while maintaining high flow efficiency.
The IP65 sealing rating safeguards internal components from dust and water ingress. Explosion protection certification Ex-i makes it suitable for hazardous environments. A sealed coil enhances operational reliability and longevity.
Manufactured in Germany under strict quality control measures. Discover this and other high-performance Solenoid Valves at EnvMart for reliable industrial fluid control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this solenoid valve is 10 bar.
The orifice diameter of the Burkert 221601 model is 10 mm.
This valve operates within a temperature range of -10°C to 80°C.
It has explosion protection certification Ex-i, making it suitable for intrinsically safe operation in hazardous areas.
The flow factor Kv for this solenoid valve is 1.9 m³/h.
The default valve position is normally closed (NC).
This model requires a supply voltage of 230V AC.
The valve has an IP65 ingress protection rating, ensuring protection against dust and water ingress.
The inlet port size of the valve is G3/8.
The valve body is constructed from brass, providing durability and corrosion resistance.
This valve is suitable for use with water, inert gases, compressed air, vacuum systems, heating, refrigeration, and water treatment.
This solenoid valve is manufactured in Germany under strict quality control measures.
