Texas Instruments 4-Channel Buffer & Line Driver, 3 State, Non-Inverting, 48-Pin TSSOP SN74LVTH16244ADGGR

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments 4-Channel Buffer & Line Driver, 3 State, Non-Inverting, 48-Pin TSSOP SN74LVTH16244ADGGR

Name: Texas Instruments 4-Channel Buffer & Line Driver, 3 State, Non-Inverting, 48-Pin TSSOP SN74LVTH16244ADGGR
Brand: Texas Instruments
SKU: 372497
Price: 20.22 USD
Availability: InStock



Category Line Interface ICs Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Brand	Texas Instruments
Height	1.2mm
Length	12.6mm
Model	SN74LVTH16244ADGGR
Width	6.2mm
Mount Type	Surface
Compatibility	Input LVTTL/TTL, Output LVTTL
Output type	3 State
Series	SN74LVTH16244A
Input Type	CMOS
Maximum Operating Temperature	125°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Polarity	Non-Inverting
IC Type	Buffer & Line Driver IC
Number Of Channels	4
Pin Count	48
Maximum Supply Voltage	3.6V
Logic Family	74LVT
Logic Function	Buffer & Line Driver
Minimum Supply Voltage	2.7V
Maximum High Level Output Current	-32mA
Maximum Propagation Delay Time @ CL	6.2ns
Supply Current	5mA
Maximum Low Level Output Current	64mA

Key Features

Operates with a low voltage BiCMOS logic family suitable for 2.7 to 3.6 V supply voltage range.
Contains 4 channels with CMOS input type and 3 state output for flexible line driving.
Surface mount type with a compact 1.2mm height, 12.6mm length, and 6.2mm width dimensions.
Maximum propagation delay time at capacitive load is 6.2 nanoseconds ensuring fast switching.
Operating temperature range from -40°C to 125°C enables operation in harsh environments.
Maximum low and high level output currents are 64mA and -32mA respectively for efficient signal driving.
Compatibility supports input LVTTL/TTL logic levels with LVTTL output.
Supply current is low at 5mA suitable for power-sensitive applications.

Product Description

Texas Instruments model SN74LVTH16244ADGGR is a 4-channel buffer and line driver integrated circuit designed with 3 state, non-inverting outputs, packaged in a 48-pin TSSOP for surface mounting applications.

This device belongs to the 74LVT family, providing low-voltage BiCMOS logic operation between 2.7 and 3.6 volts. It delivers excellent propagation delay times of 6.2 nanoseconds at capacitive loads, making it suitable for high-speed digital circuits.

Featuring CMOS input types and 3 state outputs, it supports interface buffering and line driving with output currents of up to 64mA low-level and -32mA high-level drive capabilities, ensuring robust signaling across complex PCB layouts.

Its compact dimensions of 12.6mm length, 6.2mm width, and 1.2mm height enable integration into space-constrained designs while surface mount packaging simplifies automated manufacturing.

The device operates reliably over a wide temperature range from -40°C to 125°C, catering to industrial, telecommunications, computing, and other electronic applications requiring durable and efficient Line Interface ICs.

Operates with low-voltage BiCMOS logic for energy-efficient performance. 4-channel buffer and line driver with 3 state outputs ideal for bus systems. Surface mount design in TSSOP package for compact PCB footprint. Supports TTL and LVTTL input compatibility with LVTTL output standards.

High-speed operation with maximum 6.2ns propagation delay at capacitive load. Wide operating temperature range from -40°C to 125°C for harsh environment use. Maximum output currents of 64mA (low) and -32mA (high) for strong signal drive.

Low supply current of 5mA minimizing power consumption in digital circuits. Ideal for use in automotive, industrial, communication, and computing systems requiring precise line interfacing.

This 4-channel buffer and line driver IC by Texas Instruments offers reliable, high-performance digital signal conditioning making it a preferred choice for line interface applications within semiconductors category.

Explore more electronics components and semiconductor solutions on EnvMart for your industrial, laboratory, and commercial projects.
