Wurth Elektronik Pink Tactile Switch SPST 50mA 12 V dc Through Hole, 1.3 mm Actuator Length, Right Angle 431256038736

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik Pink Tactile Switch SPST 50mA 12 V dc Through Hole, 1.3 mm Actuator Length, Right Angle 431256038736

Name: Wurth Elektronik Pink Tactile Switch SPST 50mA 12 V dc Through Hole, 1.3 mm Actuator Length, Right Angle 431256038736
Brand: Wurth Elektronik
SKU: 369937
Price: 59.14 INR
Availability: InStock



Category Tactile Switch Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Height	3.85mm
Length	7mm
Width	6.85mm
Mount Type	Through Hole
Maximum Operating Temperature	85°C
Contact Configuration	SPST
Switch Configuration	(On)-Off
Minimum Operating Temperature	-40°C
Terminal type	Solder
Standards/Approvals	RoHS
Switch Operation	Momentary
Actuator Colour	Pink
Actuator Length	1.3mm
Contact DC Voltage	12V dc
Actuator Style	Tactile
Actuator Orientation	Right Angle
Switch Contact Current	50mA
Operating Force	3.53N
Mechanical Life	200000Cycles

Key Features

The switch is designed for right angle actuator orientation operation.
It features a mechanical life of 200,000 cycles ensuring durability.
The operating force required is 3.53N providing tactile feedback.
The mount type is through hole with solder terminal type.
Suitable for operating temperatures ranging from -40°C to 85°C.
Non-illuminated actuator style offering simple tactile operation.
Compliant with RoHS standards ensuring environmental safety.
Originating from China as the country of manufacture.

Product Description

Wurth Elektronik 431256038736 Pink Tactile Switch is a compact, reliable tactile switch featuring a pink actuator with a length of 1.3 mm designed for momentary SPST operation. This through hole switch supports a contact current of 50mA and a DC voltage rating of 12 V, suitable for delicate electronic applications requiring precise tactile feedback.

The switch body measures 7 mm in length, 6.85 mm in width, and 3.85 mm in height, making it ideal for compact PCB designs where space is critical. The actuator style is tactile with a right angle orientation and requires an operating force of 3.53N, providing noticeable actuation feedback to the user.

It features silver-cladded stainless steel contacts and a steel cover ensuring electrical reliability and mechanical robustness with a mechanical life expectancy of 200,000 cycles.

Operating temperature ranges from -40°C to 85°C accommodate various industrial and commercial environments. The solder terminal type and through hole mount make it suitable for standard PCB soldering processes, including wave soldering at 260°C for up to 10 seconds.

This switch complies with RoHS environmental standards and is manufactured in China. The switch is SPST configuration and momentary operation type. Actuator color is pink with a tactile style and right angle orientation.

Operating force is 3.53N with mechanical life of 200,000 cycles. Dimensions: 7 mm length, 6.85 mm width, 3.85 mm height. Electrical rating: 50mA current, 12 V dc voltage. This tactile switch is ideal for electronics, electrical automation, and control systems requiring precise momentary switch input.
