Crydom CW48 Series Panel Mount Solid State Relay 25A Load 660V AC Load 280V AC Control
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 58.4mm |
| Length | 45.7mm |
| Model | CW48 |
| Mount Type | Panel |
| Output type | SCR |
| Series | CW48 |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Switching Function | Zero Cross |
| Maximum Load Current | 25A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 660V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 20V ac/dc |
| Maximum Control Voltage | 280V ac |
| Off State Leakage Current | 1mA |
Key Features
- Equipped with SCR output type suitable for heavy industrial loads.
- Supports maximum control voltage of 280V AC and minimum control voltage of 20V AC/DC.
- Mount type designed for secure panel installation with screw terminal type.
- Features zero cross switching function ensuring reduced electrical noise during switching.
- Operates reliably between -30°C to 80°C ambient temperature range.
- Compact dimensions of 58.4mm height and 45.7mm length enable efficient panel space usage.
- Incorporates an LED input status indicator for easy operational feedback.
- Complies with RoHS standards ensuring environmental and safety compliance.
Product Description
Crydom CWU4825P Solid State Relay from the CW48 Series is a panel mount relay designed for heavy industrial automation applications requiring reliable switching of AC loads up to 25 amps and voltages up to 660V AC.
This solid state relay features an SCR output type which provides efficient handling of heavy industrial loads with superior durability. The zero cross switching function helps minimize electrical noise and switch loads safely by engaging at zero voltage crossing points.
With a minimum control voltage of 20V AC/DC and a maximum control voltage of 280V AC, the CWU4825P can adapt to a variety of control signal sources, ensuring versatile integration into industrial systems. The panel mount design uses screw terminals for secure and easy installation in control panels.
This relay operates reliably over a broad temperature range from -30°C to 80°C. Its compact dimensions of 58.4mm in height and 45.7mm in length allow it to fit efficiently in constrained panel spaces.
The device also includes an LED input status indicator for quick operational visual feedback, enhancing maintenance efficiency. It complies with RoHS environmental standards, verifying adherence to safety and regulatory requirements. Additionally, the off state leakage current is kept low at 1mA, contributing to energy-efficient operation.
SCR output type for heavy industrial loads. Zero cross switching reduces electrical noise. Wide operating temperature range of -30°C to 80°C. Compact panel mount design with screw terminals. LED status indicator for input signal.
Low off state leakage current of 1mA. Compliant with RoHS standards. Capacitance of 8pF ensures switching stability. Supports control voltages from 20V AC/DC to 280V AC. Handles maximum load current of 25A at up to 660V AC load voltage.
This product is ideal for use in industrial automation, manufacturing control systems, process control panels, and other applications requiring reliable and efficient AC load switching. Explore more solid state relay options in the Electronics & Electricals > Relays & Contactors > Solid State Relay category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model can handle a maximum load current of 25A.
It supports a maximum load voltage of 660V AC.
The relay operates with a minimum control voltage of 20V AC/DC and a maximum control voltage of 280V AC.
It features an SCR output type suitable for heavy industrial loads.
It operates reliably within a temperature range of -30°C to 80°C.
The dimensions are 58.4mm in height and 45.7mm in length.
The zero cross switching function helps minimize electrical noise and allows for safe load switching at zero voltage crossing points.
It is designed for panel mounting with screw terminals for secure installation.
The off state leakage current is kept low at 1mA, contributing to energy-efficient operation.
Yes, it complies with RoHS standards, ensuring adherence to safety and regulatory requirements.
The capacitance is 8pF, which ensures switching stability.
It is ideal for use in industrial automation, manufacturing control systems, and process control panels requiring reliable AC load switching.
