onsemi Dual Operational Amplifier 8-Pin MSOP 3V to 32V Supply Voltage LM2904DMR2G

onsemi LM2904DMR2G is a dual operational amplifier designed for surface mount applications in electronics and semiconductor circuits. Packaged in an 8-pin MSOP, it supports single supply voltage operation over a broad range of 3V to 32V, making it suitable for diverse industrial, automotive, and laboratory applications.

This amplifier features true differential inputs and internally compensated circuits, providing accurate and stable amplification with low input bias currents and a typical input offset voltage of 7 mV. The device incorporates internal ESD clamps on all inputs to enhance robustness against electrostatic discharge.

The compact footprint of the 3.1mm by 3.1mm MSOP package combined with an overall height of 0.95mm facilitates high-density PCB layouts. It supports operation in harsh environments with an extended operating temperature from -40°C to 105°C and is compliant with the AEC-Q100 automotive standard, highlighting its reliability.

Applications include integrators, comparators, voltage clamps, current regulators, and linear voltage regulators, making the LM2904DMR2G highly versatile for analog and power management circuits in industrial machinery, automotive electronics, and instrumentation.

Dual channel operational amplifier with surface mount MSOP packaging. Single supply operation from 3V to 32V voltage range. True differential input stage minimizing external biasing requirements. Low input bias currents for precision signal amplification.

Internal ESD protection enhances device longevity. Wide operating temperature suitability for harsh environments. Automotive grade compliance ensures robust performance under automotive conditions. Compact dimensions support high-density applications and space-saving designs.

Designed for versatile roles including amplifiers, regulators, and comparators across industries.
