Samtec SQT Series Straight Through Hole PCB Socket, 2-Contact, 1 Row, 2 mm Pitch, 5.5 A, 450 V, Liquid SQT-102-01-L-S

Samtec SQT-102-01-L-S is a high-quality straight through hole PCB Socket designed for board-to-board applications. Featuring 2 contacts arranged in a single row with a 2 mm pitch, this socket ensures precise and reliable electrical connections ideal for industrial and electronic component assemblies.

The socket's housing is made from black liquid crystal polymer (LCP) providing excellent mechanical strength and temperature resistance. Its contacts are crafted from bronze material and plated with 0.25 μm gold, enhancing conductivity and corrosion resistance. The post-plating on the PCB tails is matte tin, facilitating soldering processes.

Rated for 5.5 A current at 20 °C and supporting up to 450 V, this component is suitable for demanding electronic environments. Its operating temperature range is broad, from -55 °C to 125 °C, allowing utility in diverse climates and applications including industrial control systems, instrumentation, and power electronics.

The through-hole mounting type and straight orientation enable secure placement on printed circuit boards and ease of assembly in manufacturing lines. The above board height is 6.35 mm with a post length of 2.29 mm, accommodating tight installation spaces.

This product is part of the SQT series known for ruggedness and durability. Available configurations include single row vertical (SQT-1xx-01-L-S), horizontal (SQT-1xx-01-L-x-RA), and double row vertical (SQT-1xx-01-L-D).

The socket complies with no specific approvals but meets standard industrial expectations for quality and performance. Its black LCP insulator ensures excellent electrical insulation properties. The socket is ideal for manufacturing, electronic assembly, and repair environments requiring reliable board-to-board connections.

Samtec's SQT series sockets serve industrial, electronics manufacturing, instrumentation, and laboratory applications. This model supports efficient soldering for production processes and offers durability for long-term electronic device reliability.
