Samtec 2-Contact 1 Row 2 mm Pitch Straight Through Hole Board-to-Board PCB Socket SQT-102-01-L-S

Samtec SQT-102-01-L-S PCB Socket is a high-quality 2-contact, single-row, 2 mm pitch straight through hole board-to-board connector, ideal for electronic industrial applications. This socket is constructed with a liquid crystal polymer (LCP) housing known for its robustness and thermal resistance, operating effectively between -55°C and 125°C.

The contacts are crafted from bronze and plated with gold, ensuring excellent electrical conductivity and corrosion resistance. With a current rating of 5.5 A at 20°C and a voltage rating of 450 V, this socket supports reliable and stable electrical performance in demanding environments.

Designed for through-hole mounting with a straight orientation, it provides a secure mechanical and electrical connection on printed circuit boards. The rugged design includes 0.5 mm square Tiger Buy contacts plated with 0.25 µm gold on the contact area and matte tin plating on the PCB tails for durability and easy soldering.

The socket measures an above-board height of 6.35 mm and post length of 2.29 mm, making it suitable for space-sensitive applications. The black LCP insulator material provides excellent electrical insulation and thermal stability.

This Samtec SQT Series socket is compatible with mating TMM SMT headers and through-hole headers, facilitating versatile board-to-board system designs in industrial, manufacturing, electronics assembly, and prototype development environments.

The socket’s liquid crystal polymer housing ensures durability under harsh conditions. Gold-plated bronze contacts offer enhanced electrical performance and corrosion resistance. Wide operating temperature range supports diverse industrial applications.

Through-hole mounting with straight orientation provides secure PCB connections. Compact design with precise pitch and post length accommodates tight layouts. Rugged socket construction supports reliable long-term use in demanding environments.

Compatible with TMM SMT and through-hole headers for ease of integration. Ideal for electronics manufacturing, industrial equipment, and power connectors. Explore more advanced PCB Sockets and connectors within EnvMart’s Electronics & Electricals Power Connectors category for reliable components tailored to your industrial projects.
