Samtec SLW Series Straight Through Hole PCB Socket 50-Contact 2 Row 2.54 mm Pitch Solder SLW-125-01-G-D

Samtec SLW-125-01-G-D is a high-quality straight through hole PCB socket designed for electronic applications requiring reliable board-to-board connections. It features 50 contacts arranged in 2 rows with a standard 2.54 mm pitch solder termination. The housing material is black glass-filled polyester, providing excellent mechanical strength and insulation, suitable for various industrial and manufacturing environments.

The socket includes phosphor bronze tuning fork style Tiger Buy contacts with a 0.51μm gold plating on the contact surfaces, enhancing signal integrity and corrosion resistance. Operating voltage is rated at 550V with a current capacity of 7.1A, making it suitable for medium power applications. It maintains stable performance across a wide temperature range, from -55°C minimum to 125°C maximum, supporting demanding industrial and laboratory conditions.

The product features a low profile design with a stacking height of 10mm and a solder tail length of 3.25mm, facilitating efficient PCB mounting. The contact gender is female with a straight orientation and a through-hole mount type for secure and reliable installation. This series is compatible with TLW, TSM, and TSW series square post headers, allowing flexible system configurations.

These SLW series sockets are widely used in electronics manufacturing, power connectors assemblies, test equipment, aerospace, and other technical applications requiring precise and durable connections. The robust construction and high-quality materials ensure long service life and dependable operation in challenging environments.

Designed for board-to-board connection with a low profile and 10mm stacking height. Constructed with black glass-filled polyester housing for durability. Features phosphor bronze contacts with 0.51μm gold plating for reliable conductivity.

Operates within temperature range from -55°C to 125°C and voltage up to 550V. Female contact gender with solder mount type and straight orientation. Compatible with TLW, TSM, and TSW series square post headers for versatile mating options.

Rated for a current of 7.1A ensuring stable electrical performance. Explore the extensive Samtec product range and related PCB Sockets at EnvMart to find compatible components for your industrial or laboratory setups.
