Samtec MPS Series Right Angle Through Hole PCB Socket 8-Contact 1 Row 5 mm Pitch Solder MPS-08-01-01-L-RA-SD

Samtec MPS-08-01-01-L-RA-SD is a high-quality right angle through hole PCB socket designed for board-to-board connections in electronic and electrical applications.

The socket is engineered to carry a current of up to 41.7 amperes and supports voltages up to 848 volts, making it suitable for demanding power applications. The termination type is solder, and the mount type is through hole, providing secure and stable electrical and mechanical connections on printed circuit boards.

Constructed with copper contact material and plated with 0.25 μm gold on contact areas, this socket ensures excellent conductivity and resistance to corrosion. The PCB tails are matte tin plated for effective soldering. The black LCP (liquid crystal polymer) insulator material provides robust mechanical strength and resistance to temperature extremes ranging from -55 to 125 degrees Celsius.

The design includes Ø3.56 mm screw down holes on the right angle orientation variant to secure the socket on PCBs of 1.6 mm thickness. When mated with the corresponding MPT series header systems from Samtec, the assembly achieves a stack height of approximately 14 mm, optimizing space efficiency in electronic assemblies.

This MPS series socket is primarily used in industrial, laboratory, and manufacturing environments requiring reliable and durable PCB interconnect solutions. The product complies with no specific standards or approvals but follows stringent Samtec quality manufacturing processes.

Designed for board-to-board connection with right angle orientation. Supports high current of 41.7 amperes and voltage up to 848V. Through hole mount type ensures stable soldered connection on PCB. Constructed with copper contacts plated in gold for enhanced conductivity and corrosion resistance.

Features black LCP insulator material for durability and temperature stability. Operates reliably within a temperature range from -55 to 125 degrees Celsius. Includes Ø3.56 mm screw down holes for secure mounting on 1.6 mm thick PCBs.

Compact 14 mm stack height when mated with compatible headers.

Explore the Samtec MPS series right angle PCB Sockets on EnvMart for dependable, precision board-to-board connector solutions in electronics manufacturing, power connections, and industrial applications.
