Crydom Solid State Relay, 100 A Load Current, Panel Mount, 48V dc Load Voltage, 32V dc Control DC60D100C
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 32.9mm |
| Length | 58.2mm |
| Model | DC60D100C |
| IP Rating | IP20 |
| Width | 22.6mm |
| Mount Type | Panel |
| Output type | MOSFET |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Capacitance | 8pF |
| Minimum Operating Temperature | -30°C |
| Terminal type | Screw |
| Switching Function | Instantaneous Switching |
| Maximum Load Current | 100A |
| Standards/Approvals | CE, RoHS, UL |
| Maximum Load Voltage | 48V dc |
| Minimum Load Voltage | 1V dc |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 0.1mA |
| On State Resistance | 15Ω |
Key Features
- Supports panel mounting with screw terminal connections for secure installation.
- Operates within a temperature range of -30°C to 80°C for industrial reliability.
- Features an IP20 rating for protection against solid objects larger than 12mm.
- Incorporates MOSFET output type with instantaneous switching functionality.
- Includes contact configuration of SPST and on-state resistance of 15 ohms.
- Complies with CE, RoHS, and UL standards ensuring quality and safety.
- Low off-state leakage current of 0.1mA and capacitance of 8pF for efficient operation.
Product Description
Crydom DC60D100C Solid State Relay offers reliable performance with a maximum load current of 100A and load voltage up to 48V dc, ideal for industrial and automation applications. Its panel mounting design and screw terminals facilitate easy and secure installation on control panels.
The relay operates effectively in harsh environments with an operational temperature range from -30°C to 80°C and an IP20 finger-safe rating providing protection against solid foreign objects. Featuring MOSFET output type and instantaneous switching function, it ensures fast and efficient control of electrical loads.
Compact dimensions of 58.2mm (length), 32.9mm (height), and 22.6mm (width) allow for space-saving integration in layouts. The SPST contact configuration and low on-state resistance of 15 ohms contribute to minimal power loss and efficient current flow.
Supports panel mounting with screw terminals for connectivity. Rated for a maximum load current of 100A and load voltage of 48V dc. Operates within industrial temperature range of -30°C to 80°C. IP20 protection providing finger-safe design.
Compact dimensions for versatile panel integration. Low off-state leakage current and capacitance promote efficiency. Compliance with CE, RoHS, and UL certifications ensures safety. Ideal for robotics, I/O subsystems, and medical technology applications.
This Crydom solid state relay is suitable for diverse industrial, automation, and control system settings, providing durable, high-performance switching. The robust design and compliance with industry standards make it a reliable component for electric load management.
Explore more Solid State Relay solutions and related automation equipment in the Electronics & Electricals section on EnvMart for optimized industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this solid state relay is 100A.
This model supports a maximum load voltage of 48V dc and a minimum load voltage of 1V dc.
The relay requires a control voltage range of 4V dc to a maximum of 32V dc.
It incorporates a MOSFET output type, allowing for instantaneous switching functionality.
The relay operates effectively within a temperature range of -30°C to 80°C.
It has an IP20 rating, providing protection against solid objects larger than 12mm.
The dimensions are 58.2mm in length, 32.9mm in height, and 22.6mm in width.
This model supports panel mounting with screw terminal connections for secure installation.
It features an SPST contact configuration, which allows for single-pole, single-throw switching.
The on-state resistance is 15 ohms, contributing to minimal power loss during operation.
It complies with CE, RoHS, and UL standards, ensuring quality and safety.
The off-state leakage current is 0.1mA, which promotes efficient operation.
