Lumberg Minimodul Series Straight Through Hole PCB Header, 3 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 03

Lumberg 2,5 MSF/O 03 Minimodul Series Straight Through Hole PCB Header offers a compact and reliable solution for circuit board connections requiring a 2.5 mm pitch with 3 contact points. This PCB header features a shrouded, straight orientation for enhanced protection, and is designed specifically for wire-to-board connector systems.

The contacts are made of brass with tin plating to ensure optimal electrical conductivity and corrosion resistance, while the housing is composed of glass filled polyamide providing mechanical strength and an ability to operate at temperatures ranging from -40°C to 120°C.

With a current rating of 5A and voltage rating of 160V, this header supports low load and signal applications commonly found in consumer electronics, industrial controls, and embedded systems. The termination type is solder, making it suitable for PCB soldering processes.

The Minimodul Series connectors are designed for easy harnessing of single leads and flat cables using established crimp technology, especially beneficial for low to medium volume production environments. The shrouded design safeguards the male contacts and ensures secure mating with compatible crimp housings (3114 Series).

Provides a 2.5 mm pitch straight through hole PCB header for wire-to-board applications. Houses 3 brass contacts with tin plating for optimal conductivity and corrosion resistance. Constructed from glass filled polyamide to ensure durability and heat resistance up to 120°C.

Supports a maximum current rating of 5A and operating voltage of 160V. Single row with shrouded housing protects contacts and ensures secure mating. Designed for solder termination and male contact gender. Operates reliably between -40°C and 120°C for diverse environments.

Compatible with crimp contact housings (3114 Series) for easy cable harnessing. Suitable for signal and low load current applications in industrial and electronics assembly. Enables efficient low and middle-volume production with well-established crimp technology.

This PCB header is ideal for electronics manufacturing, prototyping, and assembly line use cases demanding high reliability and precision in signal transmission. Engineers and production technicians will appreciate its standardized pitch and robust materials that assure long-term durability.
