Molex Mega-Fit Series Right Angle Through Hole PCB Header, 6 Contacts, 5.7 mm Pitch, 2 Row, Shrouded 172064-0006

Molex 172064-0006 Mega-Fit Series Right Angle Through Hole PCB Header is a high current density connector designed for power and electronic systems requiring compact and reliable wire-to-board connections. With a 5.7 mm pitch and 2 rows of 6 gold-plated contacts, this shrouded PCB header ensures positive locking with an audible click, reducing the risk of improper mating. The housing is made from high temperature thermoplastic compliant with UL 94 V-0 flammability and Glow-Wire standards, ensuring enhanced safety.

Operating temperature ranges from -40°C to 120°C, making it suitable for various industrial, commercial, and electronic applications. The connector supports 23A current per circuit and 600V voltage, meeting demanding power transmission requirements. Its through hole mount and right angle orientation facilitate secure PCB integration with additional retention and location features to stabilize the assembly.

The copper alloy contacts plated with gold provide excellent conductivity and corrosion resistance. Fully isolated terminals protect during handling and mating, improving durability and ensuring reliable electrical connections over the product lifecycle.

This PCB header is ideal for use in sectors including industrial machinery, power distribution, telecommunications, and automotive electronics. For mating connectors, compatible UL 94 V-0 Mega-Fit receptacles are recommended.

Rated for 23A current per circuit for high power density performance. Constructed with high temperature thermoplastic housing ensuring UL 94 V-0 flammability rating. Gold-plated copper alloy contacts provide excellent conductivity and corrosion resistance.

Designed with PCB retention and location features for secure mounting and positive locking with audible click. Suitable for operation between -40°C and 120°C temperature range. Right angle orientation with through hole mount type simplifies PCB assembly.

Terminations are solder type for reliable electrical connection. Voltage rating up to 600V supports a wide variety of power applications. Fully isolated terminals ensure protection during handling and mating processes. Complies with Glow-Wire standards for assured safety and reliability.
