Molex Mega-Fit Series Straight Through Hole PCB Header 4 Contact 5.7 mm Pitch 2 Row Shrouded 172065-0004
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 600V |
| Brand | Molex |
| Orientation | Straight |
| Current | 23A |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Copper Alloy |
| Series | Mega-Fit |
| Termination Type | Solder |
| Maximum Operating Temperature | 120°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 5.7mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.73mm |
Key Features
- High current rating of 23 amps per circuit.
- Constructed with Liquid Crystal Polymer housing material providing durability.
- Gold plated copper alloy contacts ensure reliable electrical conductivity.
- Through-hole mount type with straight orientation for PCB installation.
- Operates safely from -40°C to 120°C temperature range.
- Features a positive locking mechanism with audible click when mated.
- Terminations are solder type for secure electrical connection.
- Tail pin length measures 3.73 mm for reliable insertion.
Product Description
Molex 172065-0004 Mega-Fit Series Straight Through Hole PCB Header is a high-performance connector featuring 4 contacts arranged in 2 rows with a 5.7 mm pitch. This shrouded PCB header is designed for secure and reliable wire-to-board connections in diverse industrial and commercial electronic applications.
The connector includes a robust Liquid Crystal Polymer housing that offers high durability and a UL 94 V-0 flammability rating, making it suitable for demanding environments. Its copper alloy contacts are gold plated to ensure excellent electrical conductivity and corrosion resistance. The header utilizes through-hole mount technology with straight pin orientation, optimized for PCB installation stability.
Rated for 23 amps per circuit and up to 600 volts, this Mega-Fit header handles high current densities in compact pitches. It operates safely between -40°C and 120°C, catering to a wide temperature range encountered in industrial, automotive, and power electronics. The termination type is solder, providing reliable mechanical and electrical connection on the PCB.
The product features a positive locking design that produces an audible click when fully mated with compatible receptacles, enhancing assembly confidence and connection integrity. Its 3.73 mm tail pin length allows precise PCB insertion and retention. The shrouded housing design offers additional protection against accidental contact and improves durability during handling.
This PCB header is well suited for power connectors in industrial control systems, power supplies, telecommunications, and other high-reliability applications requiring compact, high-current wire-to-board interconnect solutions.
High current rating of 23A per circuit. Liquid Crystal Polymer housing with UL 94 V-0 flammability rating. Gold plated copper alloy contacts for reliable connectivity. Straight orientation and through-hole mount type for PCB assembly.
Operates between -40°C to 120°C temperature range. Positive locking feature with audible mating confirmation. Solder termination for robust PCB connection. Tail pin length of 3.73 mm. Voltage rated at 600 V suitable for power applications.
Manufactured in China with industry-standard quality. Explore more PCB Headers and Power Connectors in the Electronics & Electricals category at EnvMart for comprehensive industrial and commercial connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a high current rating of 23 amps per circuit, making it suitable for high-density applications.
The voltage rating for this header is 600 volts, which is appropriate for power applications.
It features a housing made from Liquid Crystal Polymer and contacts made from gold plated copper alloy, ensuring reliable electrical conductivity.
This PCB header operates safely within a temperature range of -40°C to 120°C, suitable for various industrial environments.
It utilizes a through-hole mount type with a straight orientation for stable PCB installation.
The tail pin length measures 3.73 mm, facilitating reliable insertion into the PCB.
This model features 4 contacts arranged in 2 rows, designed for secure wire-to-board connections.
Yes, it includes a positive locking mechanism that provides an audible click when mated, ensuring connection integrity.
The termination type is solder, which provides a robust mechanical and electrical connection on the PCB.
This header is part of the Mega-Fit Series, known for its high-performance capabilities in compact designs.
This PCB header is manufactured in China, adhering to industry-standard quality.
