STMicroelectronics Operational Amplifier 1 MHz 14-Pin SOIC Surface Mount 6-36V TL064CDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | TL064CDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | TL064 |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Low Harmonic Distortion | 0.01% (TL07x) |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-7465Brand: STMicroelectronicsManufacturers Part No.: TL064CDT |
| Pin Count | 14 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 6V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 10 nA |
| Vos - Input Offset Voltage | 20 mV |
| Slew Rate | 3.5V/μs |
| Input Offset Current | 5 nA |
| High Slew Rate | 16 V/μs (TL07x, TL08x), 3.5 V/μs (TL06x) |
Key Features
- The device operates with low input bias and offset currents for precision amplification.
- It supports a wide temperature range from 0°C to 70°C for reliable performance.
- The TL064CDT offers a typical slew rate of 3.5 V/μs suitable for fast signal processing.
- Includes internal frequency compensation and output short circuit protection.
- Features low noise characteristics making it ideal for sensitive analog circuits.
- Compliant with RoHS standards ensuring environmental safety.
- Allows wide common-mode and differential voltage ranges enhancing versatility.
- Surface mount package ensures efficient PCB space utilization.
Product Description
STMicroelectronics TL064CDT is a precision operational amplifier featuring a JFET input stage characterized by low input bias current and offset voltage. Packaged in a compact 14-pin SOIC surface mount format, it is engineered for applications requiring high impedance and low distortion.
This amplifier supports a broad supply voltage range of 6 to 36 volts, making it suitable for a variety of industrial, electronic, and laboratory applications. The gain bandwidth product stands at 1 MHz, enabling effective operation in audio, signal conditioning, and measurement systems.
Designed with a slew rate of 3.5 V/μs, the TL064CDT ensures rapid response suitable for high-speed signal processing tasks. The device also provides output short circuit protection and internal frequency compensation, increasing reliability in demanding environments.
Its operational temperature range from 0°C to 70°C meets typical industrial standards, further enforcing its broad applicability. The amplifier exhibits low noise behavior and low harmonic distortion characteristics with high input impedance, facilitating precision amplification in sensitive circuits.
The TL064CDT meets RoHS compliance, supporting environmentally friendly manufacturing. Its surface mount package optimizes space on printed circuit boards, making it preferred in compact designs.
Low input bias and offset currents for precision amplification. Wide supply voltage range from 6V up to 36V. Gain bandwidth product of 1 MHz for versatile frequency response. High slew rate of 3.5 V/μs for fast signal transitions.
Output short circuit protection and internal frequency compensation. Low noise and low harmonic distortion ensure high fidelity. Temperature operation from 0°C to 70°C. Compact 14-pin SOIC surface mount package. RoHS compliant for environmentally safe operation.
This Operational Amplifier is extensively used in industrial automation, electronic instrumentation, audio equipment, and laboratory devices due to its reliable performance specifications. It effectively meets needs in power management, sensor signal conditioning, and analog computation.
Explore additional semiconductor and amplifier solutions available in the Electronics & Electricals category at EnvMart for comprehensive system design and integration.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the TL064CDT is 1 MHz, enabling effective operation in various applications requiring frequency response.
This model supports a supply voltage range from 6V to 36V, making it versatile for different applications.
The typical slew rate of the TL064CDT is 3.5 V/μs, suitable for fast signal processing tasks.
The operational temperature range for this device is from 0°C to 70°C, which meets typical industrial standards.
The TL064CDT features 4 channels, allowing for multiple signal processing tasks in one package.
The input bias current of the TL064CDT is 10 nA, which contributes to its precision amplification capabilities.
This model has dimensions of 8.75 mm in length, 4 mm in width, and 1.65 mm in height.
The TL064CDT is packaged in a 14-pin SOIC surface mount format, optimizing PCB space utilization.
Yes, it is compliant with RoHS standards, ensuring environmentally safe operation.
The input offset voltage of the TL064CDT is 20 mV, which is important for precision applications.
This operational amplifier is suitable for industrial automation, electronic instrumentation, audio equipment, and laboratory devices.
It includes output short circuit protection and internal frequency compensation, which enhance its reliability in demanding environments.
