STMicroelectronics Operational Amplifier 1.3 MHz 14-Pin 30V SOIC LM224DT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | LM224DT |
| Width | 4mm |
| Mount Type | Surface |
| Series | LM224 |
| Output Current | 70mA |
| Maximum Operating Temperature | 105°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-0717PBrand: STMicroelectronicsManufacturers Part No.: LM224DT |
| Pin Count | 14 |
| Maximum Supply Voltage | 30V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 200 nA |
| Vos - Input Offset Voltage | 7 mV |
| Slew Rate | 0.4V/μs |
| Input Offset Current | 40 nA |
| Low supply current per amplifier | 375 μA |
Key Features
- Contains four independent high gain operational amplifiers in a single package.
- Wide gain bandwidth product of 1.3 MHz enables efficient signal amplification.
- Operates with supply voltages ranging from 5V minimum to 30V maximum.
- Low input bias current of 200 nA for enhanced signal integrity.
- Input offset voltage of 7 mV ensures precise operation.
- Slew rate of 0.4 V/μs supports rapid voltage changes.
- Maximum output current of 70 mA suitable for various load conditions.
- Operating temperature range from -40°C to 105°C allows use in harsh environments.
Product Description
STMicroelectronics LM224DT is a quad operational amplifier designed for high gain and low power consumption applications. With a gain bandwidth product of 1.3 MHz and a wide supply voltage range from 5V up to 30V, it is suitable for versatile analog signal processing tasks.
The SOIC surface mount package offers a compact form factor with 14 pins, measuring 8.75 mm in length, 4 mm in width, and 1.65 mm in height, making it ideal for space-constrained electronic circuits.
This operational amplifier features a low input bias current of 200 nA and an input offset voltage of 7 mV, ensuring accuracy and stability in signal amplification. The slew rate of 0.4 V/μs enables quick response to input signal changes, while the output current can reach up to 70 mA, supporting various load requirements.
Designed to operate across a wide temperature range from -40°C to 105°C, the LM224DT is robust for industrial, automotive, and consumer electronics applications. It complies with RoHS environmental standards.
Four independent high gain amplifiers in a single IC. Gain bandwidth product of 1.3 MHz for efficient amplification. Minimum supply voltage of 5V and maximum of 30V. Low input bias current of 200 nA for signal accuracy. Input offset voltage of 7 mV guarantees precision.
Slew rate of 0.4 V/μs for fast signal handling. Maximum output current of 70 mA supports a wide range of loads. Operating temperature range: -40°C to 105°C suitable for harsh environments. Compact SOIC 14-pin surface mount package with standard dimensions.
RoHS compliant for environmental safety. These amplifiers are widely used in instrumentation, audio electronics, control systems, and signal conditioning in industrial, laboratory, and automotive grade devices. Explore more products in the Operational Amplifier category on EnvMart for comprehensive electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the LM224DT operational amplifier is 1.3 MHz, enabling efficient signal amplification.
The maximum supply voltage for this model is 30V, while the minimum supply voltage is 5V.
The input bias current of this operational amplifier is 200 nA, which enhances signal integrity.
The input offset voltage for the LM224DT is 7 mV, ensuring precise operation during signal amplification.
This operational amplifier can provide a maximum output current of 70 mA, suitable for various load conditions.
The operating temperature range for this model is from -40°C to 105°C, allowing its use in harsh environments.
The LM224DT is packaged in a 14-pin SOIC surface mount package, measuring 8.75 mm in length, 4 mm in width, and 1.65 mm in height.
The slew rate of the LM224DT is 0.4 V/μs, which supports rapid voltage changes in response to input signals.
This model contains four independent high gain operational amplifiers in a single package.
Yes, the LM224DT complies with RoHS environmental standards, ensuring safety in electronic applications.
The LM224DT is widely used in instrumentation, audio electronics, control systems, and signal conditioning in various industries.
The input offset current for this operational amplifier is 40 nA.
