Nisshinbo Micro Devices Operational Amplifier 1.3 MHz 8-Pin Surface Mount 15V DMP NJM3414AM
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nisshinbo Micro Devices |
| Height | 1.6mm |
| Length | 5mm |
| Model | NJM3414AM |
| Width | 5mm |
| Mount Type | Surface |
| Series | NJM3414 |
| Output Current | 70mA |
| Maximum Operating Temperature | 75°C |
| Package Type | DMP |
| Minimum Operating Temperature | -20°C |
| Number Of Channels | 2 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 713-9883Brand: Nisshinbo Micro DevicesManufacturers Part No.: NJM3414AM |
| Pin Count | 8 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 500 nA |
| Vos - Input Offset Voltage | 5 mV |
| Slew Rate | 1V/μs |
| Input Offset Current | 100 nA |
Key Features
- Features a 2-channel configuration with 8 pins in DMP package.
- Operates with a supply voltage range from 5V to 15V.
- Input bias current is 500 nA, suitable for low current designs.
- Has a slew rate of 1 V/μs allowing for fast response times.
- Wide operating temperature range from -20°C to 75°C ensures reliability in various environments.
- Provides a maximum output current of 70 mA for driving moderate loads.
- Compact dimensions of 5 mm length, 5 mm width, and 1.6 mm height.
- Input offset voltage is 5 mV with an input offset current of 100 nA.
Product Description
Nisshinbo Micro Devices NJM3414AM is a high output current operational amplifier designed for demanding electronic applications. Featuring a gain bandwidth product of 1.3 MHz, it supports high-frequency signal amplification with precision.
The amplifier is housed in a compact 8-pin DMP surface mount package, ideal for space-sensitive designs. Its supply voltage compatibility ranges from 5V minimum to 15V maximum, with a maximum output current of 70 mA to drive a variety of connected loads effectively.
This device operates reliably across a wide temperature range from -20°C to 75°C, making it suitable for industrial, laboratory, and consumer electronics environments. With an input bias current of 500 nA, input offset voltage of 5 mV, and input offset current of 100 nA, it ensures stable and accurate signal processing.
The sleek 5 mm by 5 mm by 1.6 mm dimension makes it optimal for modern compact PCBs requiring surface mount technology. Its slew rate of 1 V/μs allows for swift voltage changes without distortion.
2-channel operational amplifier with 8 pins for diverse applications. Surface mount DMP package offering small footprint and ease of PCB assembly. Flexible voltage supply range between 5V and 15V. High slew rate of 1 V/μs enables quick signal transitions.
Operates effectively at temperatures from -20°C to 75°C for robust use cases. Maximum output current of 70 mA designed for medium load driving requirements. Input offset voltage and current parameters provide accurate signal amplification.
Suitable for use in industrial control systems, audio electronics, signal conditioning, and general-purpose amplification tasks, the NJM3414AM is a reliable component in electronic design. Its consistent performance and compact package align with modern electronic manufacturing standards.
Explore more Operational Amplifiers and semiconductor components to enhance your electronic projects and product designs at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1.3 MHz, allowing it to support high-frequency signal amplification with precision.
It operates with a supply voltage range from 5V to 15V, making it versatile for various applications.
The maximum output current is 70 mA, which is suitable for driving moderate loads effectively.
This model has compact dimensions of 5 mm in length, 5 mm in width, and 1.6 mm in height, making it ideal for space-sensitive designs.
The input bias current for this operational amplifier is 500 nA, which is suitable for low current designs.
It operates effectively across a wide temperature range from -20°C to 75°C, ensuring reliability in various environments.
The slew rate is 1 V/μs, allowing for fast response times and quick voltage changes without distortion.
This operational amplifier features a 2-channel configuration, making it suitable for diverse applications.
The input offset voltage is 5 mV, contributing to its stable and accurate signal processing capabilities.
It is housed in an 8-pin DMP surface mount package, which is ideal for modern PCB designs.
The input offset current is 100 nA, which helps maintain accuracy in signal amplification.
This operational amplifier is suitable for use in industrial control systems, audio electronics, signal conditioning, and general-purpose amplification tasks.
