TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header, 2 Contacts, 4.14 mm Pitch, 1 1-770872-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 9.5A |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Mini-Universal MATE-N-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 4.14mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 709-9921PBrand: TE ConnectivityManufacturers Part No.: 1-770872-0 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.69mm |
Key Features
- Constructed with white UL94V-0 nylon housing offering durability and safety.
- Features shrouded, straight orientation with 1 row and brass contacts plated with tin.
- Designed for through hole mounting and solder termination for secure assembly.
- Operational temperature range from -55°C to 105°C suitable for various industrial applications.
- Rated for 9.5A current and 600V voltage providing efficient electrical performance.
- Incorporates positive locking latch and board locks to ensure secure mating and retention.
- Tail pin length measures 3.69 mm for precise PCB fitment.
- Ideal for industrial, electronic, power connector, and PCB assembly use cases.
Product Description
TE Connectivity 1-770872-0 Mini-Universal MATE-N-LOK Series PCB Header is a high-quality, straight through hole connector designed for robust wire-to-board connectivity applications. It features a 4.14 mm pitch with 2 male contacts arranged in a single row, enclosed in a white UL94V-0 rated nylon housing that ensures flame retardance and mechanical durability.
The connector's brass contacts are plated with tin, providing reliable electrical contact and corrosion resistance. It supports a current carrying capacity of 9.5A and withstands voltages up to 600V, making it suitable for demanding electronic and power connector environments.
With an operating temperature range from -55°C to 105°C, this PCB Header is suitable for a wide variety of industrial, manufacturing, electronic equipment, and power distribution applications. The connector includes a positive locking latch mechanism and PCB retention board locks that guarantee secure mating cycles and stable mounting on the circuit board.
The tail pin length of 3.69 mm facilitates precise insertion and soldering on PCB assemblies. Its shrouded design enhances contact protection and reduces the risk of accidental disconnects or damage.
Durable nylon housing with flame retardant UL94V-0 rating. 2 brass contacts with tin plating for reliable electrical connection. Straight, shrouded orientation in a single row for compact design. Through hole mounting with solder termination for strong PCB retention.
Positive locking latch and board locks secure connections and assembly integrity. Wide operating temperature range suitable for harsh industrial conditions. Rated for 9.5A current and 600V voltage in power and electronic applications.
Mates with Mini-Universal MATE-N-LOK plug housings and compatible connectors.
This connector is widely used in electronics, power connectors, PCB assembly, industrial automation, manufacturing equipment, and other commercial electronics where reliable, secure wire-to-board connection is essential.
Explore more high-performance PCB connectors and accessories at EnvMart to find suitable parts for your industrial or electronic projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 9.5A and a voltage of 600V, making it suitable for various electronic and power applications.
The pitch of this PCB header is 4.14 mm, allowing for compact arrangements in electronic assemblies.
It features a nylon housing and brass contacts plated with tin, ensuring reliable electrical contact and corrosion resistance.
The operational temperature range is from -55°C to 105°C, making it suitable for harsh industrial environments.
This unit is designed for through hole mounting with solder termination, ensuring secure assembly on the circuit board.
It incorporates a positive locking latch and board locks to ensure secure mating and retention during operation.
This PCB header has 2 male contacts arranged in a single row, facilitating wire-to-board connections.
The tail pin length measures 3.69 mm, which aids in precise PCB fitment during assembly.
This model features a shrouded design, which enhances contact protection and reduces the risk of accidental disconnects.
It belongs to the Mini-Universal MATE-N-LOK series, designed for robust wire-to-board connectivity applications.
This connector is widely used in industrial automation, manufacturing equipment, and other commercial electronics requiring secure wire-to-board connections.
The connector is manufactured in India, ensuring compliance with relevant manufacturing standards.
