Panasonic PCB Power Relay 24V DC Coil 48A Switching Current SPST HE1AN-P-DC24V-Y5
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 36.3mm |
| Length | 38mm |
| Model | HE1AN-P-DC24V-Y5 |
| Width | 33mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HE |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -50°C |
| Switching Current | 48A |
| Terminal type | Through Hole |
| Typical Applications | Machine tools, Moulding equipment, Air conditioners, Heating equipment |
| Contact Resistance | 100mΩ |
| Standards/Approvals | VDE, UL, TUV, RoHS, CSA |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-5654Brand: PanasonicManufacturers Part No.: HE1AN-P-DC24V-Y5 |
| Coil Resistance | 300Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 48V dc |
| Switching AC Voltage | 490V ac |
| Coil Power | 1.92W |
| Switching Power | 2.3kW |
Key Features
- The relay supports PCB mounting ensuring secure installation.
- It has a coil resistance of 300Ω and coil power consumption of 1.92W.
- The switching DC voltage is rated at 48V dc and AC voltage at 490V ac.
- Operating temperature ranges from -50°C minimum to 55°C maximum providing durability under harsh conditions.
- Contact material is a silver alloy, offering excellent conductivity and low contact resistance of 100mΩ.
- The relay measures 38mm in length, 33mm in width, and 36.3mm in height for compact fitting.
- It supports a high switching power of 2.3kW and is certified by VDE, UL, TUV, RoHS, and CSA standards.
- Typical applications include machine tools, moulding equipment, air conditioners, and heating equipment.
Product Description
Panasonic HE1AN-P-DC24V-Y5 PCB Power Relay is designed for industrial, commercial, and electrical automation use where reliable high current switching is required. The 24V dc coil and SPST contact configuration provide a robust solution with excellent surge resistance exceeding 10,000V. This single-side stable relay ensures longevity and resistance to contact welding thanks to its pre-tension and kick-off mechanisms.
The relay's coil resistance of 300Ω and coil power of 1.92W contribute to efficient operation. The capable switching current of 48A supports both DC voltage of 48V and AC voltage of 490V, suitable for a wide range of loads. Operating temperature ranges from -50°C to 55°C enable the device to function reliably in extreme environmental conditions.
Compact dimensions (38mm length, 33mm width, 36.3mm height) allow easy PCB mounting with through-hole terminals. Contacts are made from a high-quality silver alloy to minimize resistance and enhance electrical conductivity. This relay complies with internationally recognized standards including VDE, UL, TUV, RoHS, and CSA, ensuring safety and performance compliance.
Typical use cases span machine tools, moulding equipment, air conditioners, and heating equipment in industrial and HVAC environments. The high switching power rating of 2.3kW makes it suitable for demanding electrical loads encountered in manufacturing and automation systems.
Panasonic's HE series relays are renowned for their durability and electrical performance, offering a highly reliable solution for heavy-duty PCB mounted power switching applications. This product is manufactured in Japan, reflecting the high-quality standards of Panasonic.
The relay supports PCB mounting ensuring secure installation. Coil resistance of 300Ω reduces energy loss during coil energizing. High switching current of 48A enables control of substantial loads. Wide operating temperature range from -50°C to 55°C for harsh environments.
Certified by VDE, UL, TUV, RoHS, and CSA to meet global standards. Compact size facilitating space-efficient PCB designs. Silver alloy contacts ensure low resistance and reliable conduction. Applications include machine tools, moulding equipment, air conditioners, and heating units.
Explore further power relay products from Panasonic and other brands in EnvMart's Electronics & Electricals category to meet your industrial automation and electrical control needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current rating of 48A, allowing it to control substantial electrical loads.
This model measures 38mm in length, 33mm in width, and 36.3mm in height, making it compact for PCB mounting.
The relay operates with a coil voltage of 24V DC and has a coil power consumption of 1.92W.
It features a Single Pole Single Throw (SPST) contact configuration, suitable for various switching applications.
The operating temperature range for this unit is from -50°C to 55°C, allowing it to function in extreme conditions.
The contacts are made from a silver alloy, which provides excellent conductivity and low contact resistance of 100mΩ.
It can switch DC voltage up to 48V and AC voltage up to 490V, making it versatile for different applications.
This relay is certified by VDE, UL, TUV, RoHS, and CSA, ensuring compliance with international safety and performance standards.
Typical applications include machine tools, moulding equipment, air conditioners, and heating equipment in industrial settings.
The relay supports PCB mounting with through-hole terminals, allowing for secure installation on printed circuit boards.
The HE1AN-P-DC24V-Y5 has a high switching power rating of 2.3kW, suitable for demanding electrical loads.
The coil resistance is 300Ω, which helps reduce energy loss during coil energizing.
