Panasonic Roller Lever Micro Switch with Solder Terminal, 3A, 250V AC, SPCO AV32543-A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Model | AV32543-A |
| Series | AV3 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPCO |
| Actuator Type | Roller Lever |
| Minimum Operating Temperature | -25°C |
| Terminal type | Solder |
| Standards/Approvals | VDE, CSA, RoHS, SEMKO, UL |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-4380Brand: PanasonicManufacturers Part No.: AV32543-A |
| Switch Contact Current | 3A |
| Operating Force | 0.39N |
| Mechanical Life | 500000Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Subminiature |
Key Features
- The roller lever actuator provides smooth mechanical operation.
- Solder terminal type ensures reliable electrical connections.
- Single pole changeover (SPCO) contact configuration.
- Operates effectively in temperature ranges from -25°C to 85°C.
- Subminiature form factor with flux-resistant construction.
- Mechanical life rated for 500,000 operations.
- Standards approved including VDE, CSA, RoHS, SEMKO, and UL.
- Typical uses include communication equipment, vending machines, security systems, data systems, and medical equipment applications.
Product Description
Panasonic AV32543-A is a high precision roller lever micro switch designed for industrial and electronic applications requiring reliable performance. Its solder terminal facilitates durable and secure connections for circuits. Rated for 3A contact current at 250V AC, making it suitable for various control and automation systems.
This subminiature micro switch features a robust flux-resistant construction ensuring durability in challenging environments. It supports a wide operating temperature range from -25°C to 85°C, assuring function under diverse conditions.
The SPCO (Single Pole Changeover) contact design is optimized for switching applications where changeover capability is essential. Mechanical life expectancy of 500,000 operations highlights its extended reliability.
Typical industrial and commercial uses include communication devices, vending machines, security and alarm systems, data processing equipment, and medical devices. The refined design balances precision actuation with durability.
Panasonic's AV3 series is known for its quality and compliance with international standards including VDE, CSA, RoHS, SEMKO, and UL, underscoring safety and environmental considerations.
The roller lever actuator design offers responsive and smooth actuation. Solder terminals provide sturdy electrical termination suited for PCB mounting. Robust construction is resistant to flux penetration for enhanced durability.
Rated for 3A contact current and 250V AC voltage compatibility. Compact subminiature footprint supports space-constrained installations. Operating temperature range suitable for harsh environmental conditions. Extensive mechanical lifespan enabling long-term use in critical systems.
Compliance with multiple global certifications ensures reliable application.
This micro switch is an essential component for industries requiring dependable switching performance in electrical and automation systems. For more products like Panasonic Micro Switches, explore the Electronics & Electricals catalog at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for the Panasonic AV32543-A micro switch is 85°C.
This model features a Single Pole Changeover (SPCO) contact configuration, allowing for versatile switching applications.
The switch is rated for a contact current of 3A and a contact voltage of 250V AC.
The mechanical life of this micro switch is rated for 500,000 operations, ensuring extended reliability in use.
It operates effectively within a temperature range from -25°C to 85°C, making it suitable for various environments.
This model uses a roller lever actuator, which provides smooth mechanical operation.
The terminal type for this micro switch is solder, which ensures reliable electrical connections.
It complies with multiple standards including VDE, CSA, RoHS, SEMKO, and UL, ensuring safety and environmental considerations.
The operating force for the Panasonic AV32543-A is 0.39N, which indicates the force needed to actuate the switch.
This switch is classified as subminiature, making it suitable for space-constrained installations.
Typical applications include communication equipment, vending machines, security systems, data processing equipment, and medical devices.
The country of origin for this micro switch is India.
