Panasonic Hinge Lever Micro Switch PCB Terminal 100mA 250V ac 30V dc SPCO AVT342061-A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Model | AVT342061-A |
| Series | AVT |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPCO |
| Actuator Type | Hinge Lever |
| Minimum Operating Temperature | -25°C |
| Terminal type | PCB Terminal |
| Standards/Approvals | VDE, UR, RoHS, CSA |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 699-0570Brand: PanasonicManufacturers Part No.: AVT342061-A |
| Contact DC Voltage | 30V dc |
| Switch Contact Current | 100mA |
| Operating Force | 0.078N |
| Mechanical Life | 500000Operations |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Subminiature |
Key Features
- The hinge lever actuator provides reliable mechanical operation with a low operating force of 0.078N.
- It features SPCO contact configuration for single pole changeover functionality.
- Supports a mechanical lifespan of up to 500,000 operations ensuring durability.
- Designed with flux-resistant construction and integrally moulded terminals for PCB mounting.
- Operates effectively within temperature ranges from -25°C to 85°C for versatile environmental compatibility.
- Complies with international standards including VDE, UR, RoHS, and CSA for safety and reliability.
- Typical applications include communication equipment, vending machines, security systems, data systems, and medical equipment.
Product Description
Panasonic AVT342061-A Hinge Lever Micro Switch PCB Terminal is an industry-grade subminiature microswitch designed for high precision and reliable operation in electrical and electronic devices. Operating with a current rating of 100mA and contact voltages of 250V AC and 30V DC, this switch is ideal for delicate circuit control tasks.
The hinge lever actuator type ensures smooth, responsive switching action with an operating force of 0.078 Newtons, making it suitable for sensitive control applications. Its SPCO (Single Pole Changeover) contact configuration enables versatile circuit switching functionality.
Constructed with a flux-resistant design and integrally moulded PCB terminals, it facilitates robust soldering and stable electrical connections, enhancing PCB assembly durability. The mechanical life of 500,000 operations confirms excellent reliability over extended use periods.
Designed to operate within a temperature range of -25°C to 85°C, it is suited for a variety of environments, including communication equipment, vending machines, security systems, data processing devices, and medical instruments. It carries approvals and certifications from VDE, UL Recognized, RoHS compliance, and CSA, ensuring adherence to quality and safety norms.
Panasonic's AVT series of subminiature high precision switches are renowned for their performance in demanding industrial and commercial applications, providing consistent and accurate electrical switching with longevity.
The hinge lever actuator offers precise mechanical response. Flux-resistant construction prevents contamination of switch contacts. Integrally moulded PCB terminals support easy mounting and soldering. Mechanical life of 500,000 operations enhances durability.
SPCO contact configuration for reliable switching functionality. Wide operating temperature from -25°C to 85°C. Certified to VDE, UL Recognized, RoHS, and CSA standards.
This micro switch is integral to applications in industrial controls, automation systems, and consumer electronics where dependable, precise switching is essential. Explore further products within the Micro Switch category on EnvMart for related components and successors.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 85°C.
This micro switch has a mechanical life of 500,000 operations, ensuring long-term reliability.
The switch has a current rating of 100mA.
It features an SPCO (Single Pole Changeover) contact configuration for versatile circuit switching.
The operating force for the hinge lever actuator is 0.078 Newtons.
It supports contact voltages of 250V AC and 30V DC.
The minimum operating temperature is -25°C.
This model is designed with PCB terminals for easy mounting and soldering.
It complies with VDE, UR, RoHS, and CSA standards for safety and reliability.
Typical applications include communication equipment, vending machines, security systems, data systems, and medical equipment.
The actuator type is a hinge lever, providing reliable mechanical operation.
The country of origin for this micro switch is India.
