Panasonic Orange Tactile Switch Push Plate SPST 20mA 15V DC Surface Mount IP67

Panasonic EVQ5PLA08 is an Orange Tactile Switch featuring a push plate actuator and a single-pole single-throw (SPST) contact configuration. This surface mount tactile switch supports low current switching of 20mA at 15 V DC, suitable for precise control in electronics applications. The switch is designed to provide a unique sharp and clear click feel with low contact resistance and minimal bouncing noise, contributing to high contact reliability and a positive operating experience.

The compact 4.9mm x 4.9mm footprint and 0.8mm height actuator make the switch ideal for space-constrained circuit boards. Its mechanical life is rated at 200,000 operations, ensuring robust long-term performance. The switch operates efficiently within a temperature range of -20°C to 70°C and features an IP67 ingress protection rating that safeguards the component against dust and water ingress, making it suitable for demanding industrial and commercial environments.

The switch's actuator style is a push plate in a straight orientation with a J-Bend terminal mount type for secure surface mounting. The Orange colour actuator enhances visibility during operation. This tactile switch is RoHS compliant, verifying adherence to environmental standards and eliminating harmful substances.

Panasonic's EVQ series tactile switches are widely used across various industries, including electrical automation, consumer electronics, and control panels. Their reliable operation and easy integration make them a preferred choice for tactile control inputs in industrial, commercial, and laboratory equipment.

Provides a sharp and clear click feel for reliable operation. Surface mount design with a robust J-bend terminal for secure attachment. Rated for 20mA current at 15V DC voltage. Compact dimensions of 4.9mm length and width with 0.8mm actuator height.

Operates reliably between -20°C and 70°C temperature range. Mechanical life expectancy of 200,000 operations ensuring durability. High contact reliability with low contact resistance and low bouncing noise. Orange push plate actuator in a straight orientation provides clear tactile feedback.

RoHS compliant, ensuring environmental and safety standards are met. Manufactured in Japan with high quality and precision engineering. Explore the range of Panasonic Tactile Switches on EnvMart for trusted quality and performance in your electronics projects or industrial automation systems.
