MaxLinear Line Transceiver Differential, 8-Pin SOIC 3.3-6V BiCMOS SP3494EN-L
Specifications
| Country of Origin | India |
|---|---|
| Brand | MaxLinear |
| Height | 1.75mm |
| Length | 4.9mm |
| Model | SP3494EN-L |
| Width | 3.9mm |
| Mount Type | Surface |
| Output type | Differential |
| Series | SP3494E |
| Input Type | Differential |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| IC Type | Line Transceiver IC |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 6V |
| Logic Family | BiCMOS |
| Logic Function | Line Transceiver |
| Minimum Supply Voltage | 3.3V |
| Maximum High Level Output Current | -1μA |
| Maximum Propagation Delay Time @ CL | 100ns |
| Supply Current | 2mA |
| Maximum Low Level Output Current | 1μA |
Key Features
- This device features a BiCMOS logic family for efficient signal processing.
- It operates with a single channel supporting differential input and output.
- The transceiver is surface mount type with a compact 8-pin SOIC package.
- It offers a propagation delay of 100 ns with a supply current of 2 mA.
- Operational temperature range spans from -40°C to 85°C suitable for industrial environments.
- Pin count of 8 enables compatibility with standard interface designs.
- Minimum supply voltage is 3.3V, maximum up to 6V for flexible power options.
- Designed for line transceiver applications including RS-485 and RS-422 standards.
Product Description
MaxLinear SP3494EN-L is a line transceiver IC specialized for differential signaling and packaged in an 8-pin SOIC surface mount format. It operates within a supply voltage range of 3.3 to 6 volts and utilizes BiCMOS logic family technology, promising efficient and stable communication signal handling.
The device is a single channel transceiver suitable for use in RS-485 and RS-422 interfaces, making it ideal for industrial communication networks that require robust data integrity and noise immunity.
With a maximum propagation delay of 100 ns and low quiescent supply current of 2 mA, the SP3494EN-L ensures fast and power-efficient line driving capabilities. The operating temperature range from -40°C to 85°C enables reliable operation under harsh industrial conditions.
The 8-pin SOIC package offers a compact footprint minimizing board space, suitable for surface mount assembly methods.
The transceiver supports differential input and output signaling, reducing electromagnetic interference and enhancing communication accuracy with maximum high level output current at -1 μA and maximum low level output current at 1 μA.
BiCMOS logic family enabling efficient signal processing. Differential input/output supporting robust communication. Compact 8-pin SOIC package for surface mounting in dense circuits. Wide operating temperature range from -40°C to 85°C for industrial use.
Low supply current of 2 mA ensuring energy efficiency. Propagation delay of 100 ns allowing high-speed communication. Compatible with RS-485 and RS-422 line driver standards.
This line transceiver is extensively used in industrial automation, manufacturing equipment, building automation systems, and any application requiring reliable differential data transmission over long cables.
Explore more semiconductor products for your electronics projects and industrial applications at EnvMart.
Explore more products in our Line Interface ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates within a supply voltage range of 3.3V to 6V, providing flexibility for various applications.
The maximum propagation delay for the SP3494EN-L is 100 ns, allowing for high-speed communication.
It operates within a temperature range of -40°C to 85°C, making it suitable for industrial environments.
This model supports a single channel for differential input and output signaling.
The device is packaged in a compact 8-pin SOIC format, suitable for surface mounting.
The supply current for this line transceiver is 2 mA, ensuring energy efficiency during operation.
It is designed for compatibility with RS-485 and RS-422 line driver standards, making it ideal for industrial communication networks.
The dimensions of this model are 1.75 mm in height and 3.9 mm in width.
The maximum high-level output current for this transceiver is -1 μA.
This line transceiver utilizes a BiCMOS logic family for efficient signal processing.
It supports differential input signaling, enhancing communication accuracy and reducing electromagnetic interference.
The length of this model is 4.9 mm, contributing to its compact design.
