TE Connectivity AMPMODU MOD II Series Straight Through Hole PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 Row 5-103414-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 40V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a straight through hole mount for robust PCB installation.
- Comprised of a thermoplastic housing with black 94V-0 flame retardant properties.
- Gold-plated copper alloy contacts ensure excellent conductivity and durability.
- Designed to operate within a temperature range of -55°C to 105°C.
- Rated for 3A current and 40V voltage applications.
- Includes 3 male contacts in a single row configuration.
- Termination type is solder for secure electrical connection.
- Suitable for industrial automation and control applications requiring compact, reliable connectors.
Product Description
TE Connectivity 5-103414-1 AMPMODU MOD II Series Straight Through Hole PCB Header offers precise and reliable electrical connections for PCB assemblies with a 2.54 mm pitch and 3 contacts. This single-row, shrouded header is engineered with a black thermoplastic 94V-0 flame retardant housing providing excellent durability and safety.
The connector uses gold-plated copper alloy male contacts that deliver low resistance and enhanced connectivity, suitable for a maximum operating current of 3A and voltage rated up to 40V. The straight orientation and through-hole mounting type enable easy and secure placement on printed circuit boards with strong mechanical retention.
Operating temperatures range from -55°C to 105°C, accommodating harsh environments in industrial, automation, and control systems. The connector termination is solder type, allowing for reliable and long-lasting connections.
The AMPMODU Mod II series is widely recognized for its compact design and versatility, providing wire-to-board connections used in signal and power applications. This product enhances manufacturing efficiency by being supplied in tubes ready for insertion.
Features a straight through hole mount for robust PCB installation. Comprised of a thermoplastic housing with black 94V-0 flame retardant properties. Gold-plated copper alloy contacts ensure excellent conductivity and durability.
Designed to operate within a temperature range of -55°C to 105°C. Rated for 3A current and 40V voltage applications. Includes 3 male contacts in a single row configuration. Termination type is solder for secure electrical connection.
Suitable for industrial automation and control applications requiring compact, reliable connectors.
This PCB Header is essential for ensuring secure and stable connections in electronic equipment across industries including industrial manufacturing, automation controls, and electronic assemblies. Explore more high-quality connectors and PCB components with EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this PCB header is 2.54 mm.
It is designed to operate at a maximum temperature of 105°C.
This model includes 3 male contacts in a single row configuration.
It is rated for a maximum current of 3A.
The termination type for this connector is solder, ensuring a secure electrical connection.
The housing is made of thermoplastic, and the contacts are gold-plated copper alloy.
This model is rated for voltage applications up to 40V.
It features a through-hole mount for robust installation on printed circuit boards.
Yes, it is designed to operate within a temperature range of -55°C to 105°C, making it suitable for harsh environments.
The orientation of this model is straight.
This header is part of the wire-to-board connector system.
The country of origin for this PCB header is India.
